Indramat HDS03.2-W075N
The drive HDS03.2-W075N HDS is a product of the famous manufacturer Indramat, a legacy name in the world of automation and motion control. It is renowned for its pioneering contributions to the industry. This drive belongs to the HDS series and has built a robust portfolio of cutting-edge servo controllers and motors, driving the automation revolution in many sectors.
Technical Specifications :
The Indramat HDS03.2-W075N functions with a control voltage input of 26 V±2%. It delivers a maximum output voltage of 500 V, supporting demanding industrial tasks. This ensures stable and efficient performance in various technological areas. The drive can handle a maximum input current of 37 A and has a rated power consumption control voltage input of DC 24V (UL), consuming 25 W.
With a three-phase output, the drive can deliver a maximum output current of 40 A and reach an output frequency of up to 1000 Hz. It ensures reliable power dissipation at continuous current and continuous DC bus power, with respective values of 220 W, showcasing its capability for sustained heavy-duty performance.
The Indramat HDS03.2-W075N servo drive stands at a height of 498 mm, with a depth of 308 mm. Its width of 100 mm further emphasizes its slim profile, making it an ideal choice for installations where space is under consideration.
Operational and Installation Parameters:
The HDS03.2-W075N consisted of two ground connections to the power drive for proper installation. The drive operation is carried out with connection wires, and in case they are not ready to be connected, set up the connections with the use of minimum length cable such as one meter or having 25 mm square length at least.
The terminals TM+ and TM- are equipped for the use of temperature. The drive can bear a certain highest level of ambient temperature ranging from 45 to 55 degrees centigrade. An independent pair of shielded wires is used for the proper detection of a temperature. It is important to differentiate between the positioning of the units when connections are built between the control system and the drive.
Safety Precautions:
Verify that the shielded conductors are consistent from the main power supply to the motor connections. Ensure the cable shield is connected using a broad metal-to-metal contact area. Moreover, for cable with a length over 25mm², a specialized mounting plate can be used for attaching the shield.
The drive’s standard or external motor brakes do not provide sufficient self-protection. Maintain safety with primary measures, such as shielded fences. Check proper connections, technical ratings, and wiring before switching on the drive and protect vertical axes from falling by mechanical locks, outer braking units, or by correcting the load.
Frequently Asked Questions :
What is the highest output current rating in drive HDS03.2-W075N?
The Indramat drive has a consumption of about 40 amperes of maximum output current. This high current rating ensures the drive can handle demanding applications effectively.
Give a rating of control input voltage for HDS03.2-W075N?
The drive has a fixed value for voltage rating of 26V with a positive and negative tolerance of 2% for proper functioning. This precise control voltage ensures optimal performance and stability of the drive.
How much three-phase frequency is required for the HDS03.2-W075N drive?
The Indramat HDS03.2-W075N drive has an output frequency of 1000 Hz for operating as required. This high-frequency operation is essential for applications needing fast and precise control.
Product Specifications Table
Attribute | Specifications |
---|---|
Manufacturer | Indramat Rexroth |
Series | HDS |
