Indramat MKD112B-024-GP0-BN

The Indramat MKD112B-024-GP0-BN is a high-performance synchronous motor designed for use in potentially hazardous areas. This motor is part of the MKD series and is known for its reliability, efficiency, and safety features. This motor is functional in various industrial applications, including motion control, hydraulic, pneumatic, electrical, and mechanical systems.

Technical Specifications:

All the features of the synchronous servo motor are designed according to the typical industrial working environment. The rated frequency of the motor is 233Hzz. The motor comes in three variations depending on the temperature. Both natural and surface cooling methods can be used for cooling.

For 60K and 100K overtemperature and natural cooling modes, the motor operates at a 461V and 483V rated voltage and has a rated current of 4.9A and 12.4A, respectively. The rated power is 3.9kW for 60K and 9.9kW for 100K.

The rotor inertia of Indramat MKD112B-024-GP0-BN is 192.0 x 10-4 and produces a maximum torque of 102Nm. The maximum speed of the synchronous servo motor is 4000 rpm, which makes it ideal for various industrial applications.

Safety Features:

The motor is equipped with industry-grade protection features. Its design provides a safe operating environment. The motor prevents hazardous situations, mitigating the risk of fires and explosions. The motor can be stopped quickly with an internal motor brake. It can be activated in case of an emergency to prevent damage. Moreover, the motor features overtemperature protection, which prevents overheating and ensures safe operation.

Operating Instructions and Maintenance:

The motor should be started and operated according to the manufacturer's instructions, ensuring proper alignment and secure mounting. Regular maintenance is crucial to ensure the motor's optimal performance and longevity. This includes cleaning, lubricating, and inspecting the motor and its components.

Before putting the motor in operation, it is important to make sure that the holding brake can be opened to allow manual rotor rotation without any audible noise, such as scraping sounds. The Indramat MKD112B-024-GP0-BN must be securely and precisely mounted to the machine structure or gearbox, ensuring the motor flange is perfectly aligned and preventing any misalignment or vibrations.

Additional Features:

The motor can be equipped with resolver feedback with an integral multiturn absolute encoder option. This feedback system ensures precise control over the motor's position and speed. The motor's output direction for power and encoder connectors can be selected during assembly, offering installation flexibility.

The connectors can rotate within a range of 270°, ensuring they do not overlap and providing ease of integration into various systems. An optional holding brake can be included, providing a holding torque of 2.2 Nm. This is particularly useful in applications where the motor needs to maintain its position without power.

Frequently Asked Questions:

What is the Insulation Class of the Indramat MKD112B-024-GP0-BN?

The Indramat MKD112B-024-GP0-BN features an insulation class of F. It prevents the inflow of any dust particles and liquid. The motor has an aluminium housing.

What is the optimum temperature range for working of the Indramat MKD112B-024-GP0-BN?

The Indramat MKD112B-024-GP0-BN can operate in ambient temperatures ranging from 0°C to 40°C. Meanwhile, the Indramat MKD112B-024-GP0-BN should be stored and transported at -20 to +80°C temperature.

What is the maximum setup height of the Indramat MKD112B-024-GP0-BN?

The maximum height where the motor should be operated is 1000m above NN. Any more that would result in degradation. The utilization factor must be considered if the motor is to be operated above the maximum range.

Specs Table

Attribute	Specifications
Cooling mode	Natural
Motor overtemperature	60K / 100K
Continuous torque at standstill	28.0Nm / 33.0Nm / 42.0Nm
Peak current	98.5A
Torque constant at 20°C	1.43 Nm/A
Voltage constant at 20°C	130 V/1000min-1
Winding resistance at 20°C	0.58 ?
Winding inductance	7.6 mH
Number of pole pairs	4
Rated speed	3500 min -1

Read more
