Mitsubishi GT1455HS-QTBDE

Mitsubishi Gt1455Hs-Qtbde

Mitsubishi GT1455HS-QTBDE

Mitsubishi developed the GT1455HS-QTBDE, a high-performance HMI, for rigorous industrial tasks. Several industrial processes benefit from improved control and monitoring capabilities, increasing efficiency and dependability. Its modern industrial settings cannot function without it due to its user-friendly operation and long-term durability, guaranteed by its innovative features and durable build.

Technical Specifications:

The power source for GT1455HS-QTBDE must be 24V DC with a 4A fuse or an Ul-listed or Recognised Class 2 power supply. The 2004/108/EC European Directive for Electromagnetic Compatibility requires minimal interference with other devices and system integrity in complex settings.

The GT1455HS-QTBDE may be stored at -20°C to 60°C and operates from 0 to 50°C. It can endure steady 5–9 Hz vibration frequencies, intermittent 9–150 Hz vibration frequencies, and 10%–90% relative humidity (non-condensing conditions). Due to its tiny size (280 mm W x 240 mm H x 55 mm D) and 1.3 kg weight, the device is easily integrated into various setups.

Display characteristics include a 5.7-inch TFT colour LCD with 320 × 240 pixels (QVGA). LED lighting and 16-level brightness adjustment are its highlights. Ethernet (10/100 Mbps), RS-232 and RS-422/485 serial interfaces, and USB 1.1 Host and USB 2.0 Device interfaces are provided.

Memory is 6 MB user and 512 KB SRAM with battery backup in the GT1455HS-QTBDE. The 1024 x 1024 touch panel employs analog resistive film. The gadget is IP67 on a panel. It runs on 24V DC and uses 15W max.

Mounting:

With integrated clamps, the GT1455HS-QTBDE mounts panels. It supports horizontal and vertical mounting. The mounting cutout is 272 mm wide and 232 mm high, with 1.6 mm to 5.0 mm panel thickness. The gadget is secured with four M4 screws, recommended torque: 0.5 to 0.7 N·m. When properly placed, a front gasket seals the front panel and ensures an IP67 rating with consistent pressure.

It uses natural air conditioning. Thus, users should not block ventilation apertures to avoid overheating. For adequate grounding, connect the frame ground terminal to a suitable earth ground using a grounding wire with a minimum cross-sectional size of 2 mm².

Troubleshooting:

The GT1455HS-QTBDE includes power and fault LEDs. When the LED light goes red, something went wrong. The device's self-diagnostic functionalities check hardware status and output fault codes to aid troubleshooting. Communication diagnostics software supports error logging and status monitoring.

The input voltage range is 19.2 to 28.8 V DC, and the inrush current is 30 A or less within 1 ms. Overvoltage is II, and pollution is 2. The device can operate at 2000 meters and accepts 32-GB SDHC cards.

Mitsubishi GT1455HS-QTBDE has a shock resistance of 15 G (11 ms, three times in each direction) and protects against electrostatic discharge (ESD) to ±6 kV contact discharge and ±8 kV air discharge. The device has an acceleration of 9.8 m/s², a vibration resistance of 5-9 Hz, an amplitude of 3.5 mm, and a frequency range of 9-150 Hz. Ten to ninety percent relative humidity is stored.

Frequently Asked Questions:

What are the display specifications for the Mitsubishi GT1455HS-QTBDE?

The 5.7-inch TFT color LCD of the GT1455HS-QTBDE has a 320 x 240 pixel (QVGA) resolution. Furthermore, it comes with LED lighting to make it easy to see.

Does the Mitsubishi GT1455HS-QTBDE support Ethernet connectivity?

The GT1455HS-QTBDE includes an Ethernet interface supporting 10/100 Mbps, which makes data communication and network integration easy.

How much RAM does the Mitsubishi GT1455HS-QTBDE have?

There is 512 KB of SRAM and 6 MB of user memory on the GT1455HS-QTBDE, and it comes with a battery backup. This offers sufficient space for application settings and data.

Product Specifications Table

Attributes Specification
Display Size 5.7 inches
Display Resolution 320 x 240 pixels (QVGA)
Power Supply 24V DC
Operating Temperature 0 to 50°C
Storage Temperature -20 to 60°C
Humidity Range 10% to 90% (non-condensing)
Ethernet Interface 10/100 Mbps
User Memory 6 MB
SRAM 512 KB with battery backup
IP Rating IP67 (when panel mounted)

Mitsubishi GT1455HS-QTBDE

Regular price
Sale price
$1,800.00

This product is not available for online purchase. If you would like to receive a quote please use the button below.

Eligible for Next Day Delivery All Parts Come with 24 Month Warranty New, Refurbished and Repairs Available


We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.


All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.


Payment options

We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.

Credit Terms

We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.

Description

Mitsubishi GT1455HS-QTBDE

Mitsubishi developed the GT1455HS-QTBDE, a high-performance HMI, for rigorous industrial tasks. Several industrial processes benefit from improved control and monitoring capabilities, increasing efficiency and dependability. Its modern industrial settings cannot function without it due to its user-friendly operation and long-term durability, guaranteed by its innovative features and durable build.

Technical Specifications:

The power source for GT1455HS-QTBDE must be 24V DC with a 4A fuse or an Ul-listed or Recognised Class 2 power supply. The 2004/108/EC European Directive for Electromagnetic Compatibility requires minimal interference with other devices and system integrity in complex settings.

The GT1455HS-QTBDE may be stored at -20°C to 60°C and operates from 0 to 50°C. It can endure steady 5–9 Hz vibration frequencies, intermittent 9–150 Hz vibration frequencies, and 10%–90% relative humidity (non-condensing conditions). Due to its tiny size (280 mm W x 240 mm H x 55 mm D) and 1.3 kg weight, the device is easily integrated into various setups.

Display characteristics include a 5.7-inch TFT colour LCD with 320 × 240 pixels (QVGA). LED lighting and 16-level brightness adjustment are its highlights. Ethernet (10/100 Mbps), RS-232 and RS-422/485 serial interfaces, and USB 1.1 Host and USB 2.0 Device interfaces are provided.

Memory is 6 MB user and 512 KB SRAM with battery backup in the GT1455HS-QTBDE. The 1024 x 1024 touch panel employs analog resistive film. The gadget is IP67 on a panel. It runs on 24V DC and uses 15W max.

Mounting:

With integrated clamps, the GT1455HS-QTBDE mounts panels. It supports horizontal and vertical mounting. The mounting cutout is 272 mm wide and 232 mm high, with 1.6 mm to 5.0 mm panel thickness. The gadget is secured with four M4 screws, recommended torque: 0.5 to 0.7 N·m. When properly placed, a front gasket seals the front panel and ensures an IP67 rating with consistent pressure.

It uses natural air conditioning. Thus, users should not block ventilation apertures to avoid overheating. For adequate grounding, connect the frame ground terminal to a suitable earth ground using a grounding wire with a minimum cross-sectional size of 2 mm².

Troubleshooting:

The GT1455HS-QTBDE includes power and fault LEDs. When the LED light goes red, something went wrong. The device's self-diagnostic functionalities check hardware status and output fault codes to aid troubleshooting. Communication diagnostics software supports error logging and status monitoring.

The input voltage range is 19.2 to 28.8 V DC, and the inrush current is 30 A or less within 1 ms. Overvoltage is II, and pollution is 2. The device can operate at 2000 meters and accepts 32-GB SDHC cards.

Mitsubishi GT1455HS-QTBDE has a shock resistance of 15 G (11 ms, three times in each direction) and protects against electrostatic discharge (ESD) to ±6 kV contact discharge and ±8 kV air discharge. The device has an acceleration of 9.8 m/s², a vibration resistance of 5-9 Hz, an amplitude of 3.5 mm, and a frequency range of 9-150 Hz. Ten to ninety percent relative humidity is stored.

Frequently Asked Questions:

What are the display specifications for the Mitsubishi GT1455HS-QTBDE?

The 5.7-inch TFT color LCD of the GT1455HS-QTBDE has a 320 x 240 pixel (QVGA) resolution. Furthermore, it comes with LED lighting to make it easy to see.

Does the Mitsubishi GT1455HS-QTBDE support Ethernet connectivity?

The GT1455HS-QTBDE includes an Ethernet interface supporting 10/100 Mbps, which makes data communication and network integration easy.

How much RAM does the Mitsubishi GT1455HS-QTBDE have?

There is 512 KB of SRAM and 6 MB of user memory on the GT1455HS-QTBDE, and it comes with a battery backup. This offers sufficient space for application settings and data.

Product Specifications Table

Attributes Specification
Display Size 5.7 inches
Display Resolution 320 x 240 pixels (QVGA)
Power Supply 24V DC
Operating Temperature 0 to 50°C
Storage Temperature -20 to 60°C
Humidity Range 10% to 90% (non-condensing)
Ethernet Interface 10/100 Mbps
User Memory 6 MB
SRAM 512 KB with battery backup
IP Rating IP67 (when panel mounted)

Buying Options
Buying Options

All products are covered by Industrial Automation Co.'s 2-Year Warranty.

Condition SKU Price Warranty Availability Quantity Purchase
New GT1455HS-QTBDE-FS 2 Year Extended Warranty Call for Availability Call for Availability (877)-727-8757
