Mitsubishi GT2510-VTDB

The Mitsubishi GT2510-VTDB is a high-performing touchscreen operator terminal from the GT25 series. It is designed for various industrial applications and offers easy and efficient control. This terminal has advanced features and a sturdy design, ensuring dependability and ease of use in complex settings.

Technical Specifications:

A diverse array of built-in interfaces enhances the Mitsubishi GT2510-VTDB's connectivity options. The RS-232 interface provides a D-sub 9-pin male connector and a single channel with transmission rates ranging from 115200 to 4800 bps. Similarly, the RS-422/485 interface offers a D-sub 9-pin female connector and a single channel with identical transmission speeds.

An RJ-45 modular jack provides Ethernet connectivity through a single channel that supports 10BASE-T/100BASE-TX.The USB interface is equipped with two host channels (front and rear) that can transmit data at a maximum rate of 480 Mbps through USB-A connectors.

A single USB device channel (front face) operates with a maximum transmission rate of 480 Mbps and is equipped with a USB Mini-B connector. SDHC standards are also supported; an SD memory card receptacle can accommodate up to 32GB.

The GT2510-VTDB is powered by a 24VDC supply. It consumes no more than 34W when operating at maximum capacity, 12W in stand-alone mode, and 7W when the illumination is turned off.

The instantaneous failure time is permitted to be within ten milliseconds. The noise resistance is 500Vp-p, with a noise width of 1?s, and the frequency range is 25 to 60Hz. The device can withstand a voltage of 350 VAC for one minute between the power supply terminal and the ground. The insulation resistance is 10M? or more excellent.

Physical Specifications:

The GT2510-VTDB has a sleek black panel with IP67F front and IP2X control panel protection. The terminal is 311 x 237 x 54 mm and has a 289 x 200 mm panel cutout. It weighs 2.1 kg without mounting brackets and works with GT Works3 version 1.112S or later.

The 10.4" TFT color LCD has a VGA resolution of 640 x 480 and a display size of 211.2 x 158.4 mm. The screen can display 65536 colors with 32 intensity levels. LED lighting is non-replaceable but lasts 60,000 hours at 25°C.

Industrial Built-in Interface:

This analog resistive film touch panel has 2 x 2 dots for keys. It supports single-point contact and lasts over one million presses at 0.98N or less. The user memory has 32MB ROM for storage and 80MB RAM for operation, with 100,000 write cycles.

The GT11-50BAT lithium battery drives the internal clock, ensuring ±90 seconds per month accuracy at 25°C; the anticipated lifespan is five years. Power LEDs in blue and orange and a single-tone buzzer with adjustable tone and duration are also included. Due to its extensive features, the GT2510-VTDB can meet modern industrial standards.

Frequently Asked Questions:

What are the display features of the Mitsubishi GT2308-VTDB?

The GT2510-VTDB features a 10.4" TFT color LCD with a sharp 640 x 480 (VGA) resolution. It supports 65,536 colors and 32 brightness levels, making it easy to understand.

How many different types of connections can the GT2308-VTDB accommodate?

The GT2510-VTDB offers many connections, including an SD memory card port, Ethernet, USB (host and device), and RS-232 and RS-422/485. These interfaces make integrating with different industrial systems a breeze.

What is the Mitsubishi GT2308-VTDB's measurement and weight?

Without the mounting brackets, the GT2510-VTDB weighs only 2.1 kg and has 311 x 237 x 54 mm small dimensions. The panel cutout dimensions are 289 x 200 mm, which facilitates installation.
