TECHNICAL SPECIFICATIONS

Q312DB

The model Q312DB by Mitsubishi is a versatile main base unit capable of accommodating various modules. It features options to customize the power supply, data input/output, and intelligent functions for an optimal workstation configuration.

The model Q312DB is an incredibly efficient system, boasting superior extensibility and lightweight construction. It has successfully passed both the rigorous CE and UL standards for quality assurance.

Technical Specifications of Q312DB

Introducing the Q312DB model a robust, reliable powerhouse for module installations. Boasting an impressive 98 mm height and 439 mm width with 44.1 mm depth, all measuring up to 0.54 kilos without compromising construction stability or durability. This sleek model offers twelve available slots that promote seamless integration of its modules, resulting in peak efficiency performance.

Ideal for efficient and secure expansion, this base unit utilizes a bus cable to connect an extension unit easily. The Q312DB model is designed to be robust in the face of challenging situations, crafted from superior-grade alloys that provide excellent durability even under high-temperature conditions.

Ambient Conditions

The Q312DB model requires clean and dust-free installations in order to operate optimally. Additionally, it must be kept out of direct sunlight exposure since these conditions could lead to irregularities and damage its efficiency. Any regions with dirt or flammable gas should also be avoided for safety purposes.

To ensure efficient operation of the Q312DB model, the temperature must be kept between 0 - 55°C, and humidity should not exceed 95%. It’s imperative that there is no dew condensation, as this could potentially cause damage.

To ensure optimal performance, the Q312DB must be stored in a temperature-controlled environment with an acceptable range of -25°C to +70°C and no more than 95% relative humidity. Additionally, successful installation and operation can only take place at elevations up to 2 km above sea level.

Installation Instructions

During the installation of the Q312DB module, it is important to ensure that any metal particles or fragments do not come into contact with internal elements. To protect against potential short circuits and dust buildup in ventilation slots, a protective cover should be used at all times.

When adding additional modules to the Q312DB base unit, remember to properly remove the cover before powering on. This simple step ensures that your controller is functioning at peak performance while in its intended setting and protecting it from any damage due to overheating. Consider usability, maintainability, and durability when making placement decisions within a control panel for optimal results.

To ensure your electrical system complies with regulations, securely attach each module to the Q312DB base unit. Install a heavy-duty cabinet designed to protect circuitry from shock and cover it appropriately with a special plate. You can rest easy knowing that following these steps will meet all safety codes.

For optimal airflow and easier installation, the switchgear cabinet must be set up with a minimum of 30 mm headroom above its top. Set-up in a horizontal or vertical plane is not suggested, as these orientations do not promote adequate ventilation for this base unit model (Q312DB). It should only be mounted on an even surface to ensure mechanical stability.
