Schneider Electric 140ARI03010

This input module 140ARI03010 boasts an efficient 1 W power consumption in a standard format, making it the perfect choice for optimizing energy usage without compromising quality. The temperature probe of the model offers a maximum input capacity of 2.5 mA, adding precision to accurate readings.

Technical Description of 140ARI03010:

This Analog RTD Input 8 Channel module is the perfect option for an array of temperature measurements. It seamlessly connects up to eight 2-, 3- and 4-wire RTD sensors, allowing it to provide accurate data directly to your Quantum CPU.

The model 140ARI03010 provides detailed information regarding communication and faults with two distinct LED colors. The device has a green light to show bus communication and eight lights to indicate when channels are on. Additionally, there is a red signal to show external faults and a group of eight LEDs to highlight potential channel issues.

This innovative input module (140ARI03010) offers maximum accuracy with an absolute error of 0.1°C and a stellar linearity threshold at +/-0.01% full scale, making it the ideal choice for precision applications. Its lightweight design makes transport effortless, weighing only 0.3 kg, while its low bus current requirement ensures optimal efficiency.

The model ensures strong protection with 300 Vrms isolation between its channels and allows for quickly updated readings at 1200 ms intervals when using three wires. It also offers nine input words and a 13-bit resolution for analog inputs to ensure accuracy in each reading.

The 140ARI03010 model has an accuracy drift of +/- 0.5 degrees centigrade at 25 degree centigrade. The isolation between channels and the bus is 1780 V AC for 60 seconds with a frequency between 47 to 63 Hz. It also demands a sequence of nine 16-bit words to function properly, with the first eight utilized for input data and one more used solely to identify channel status.

To ensure successful communication, keep the magnet ring near the module side when using twisted-pair cables. In cases where a three-wire setup is necessary, levering off of a magnet ring will be invaluable for smooth transmission.

Environmental Conditions:

The model 140ARI03010 has an operational air temperature range of 0°C to 60°C and must be kept between -40°C and 85°C when in storage.

The product adheres to EU RoHS standards and is completely mercury-free. To ensure environmental safety, this model must be properly disposed of via an officially designated waste collection site €“ not in any ordinary bin.

General Instructions for the Model:

When the input of a channel exceeds its rated value, ranging warnings are issued. For user safety, the system will trigger an out-of-range bit if the channel value goes beyond 2.34% or if the wire on that channel is broken.

To ensure the 140ARI03010 model's optimal performance and safety, only trained personnel should be responsible for its installation, operation, servicing, and maintenance. The manufacturer cannot accept any risk or liability arising from improper use of this analog module.
