Schneider Electric 140ARI03010C

Schneider Electric 140Ari03010C

Schneider Electric 140ARI03010C

Regular price
$590.00
Sale price
$590.00
We currently have 1 in stock.
Checkmark

In stock - Ships Today

Checkmark

Eligible for Next Day Delivery

Checkmark

Ships From Our North Carolina Warehouse

Eligible for Next Day Delivery All Parts Come with 24 Month Warranty New, Refurbished and Repairs Available


We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.


All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.


Payment options

We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.

Credit Terms

We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.

Description

  • 140ARI03010C
  • DISCONTINUED BY MANUFACTURER
  • RTD IN 8CH CONF COATED

Buying Options
Buying Options

All products are covered by Industrial Automation Co.'s 2-Year Warranty.

Condition SKU Price Warranty Availability Quantity Purchase
New 140ARI03010C-FS $590.00 USD 2 Year Extended Warranty 1 In Stock in the U.S.A!
Quick Repairs and Great Service

Send in your item for a free evaluation and repair quote. Use our RMA form or email a repair request to service@iac.us.com , and we will contact you to assess your situation and offer shipping information.

Quick Search

All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.


TECHNICAL SPECIFICATIONS

Schneider Electric 140ARI03010C



This innovative analog input module 140ARI03010C offers a robust and reliable solution for all analog requirements. The model features a dual light array of 1 green and one red LED: the former indicating bus communication presence and the latter displaying any potential external faults. Additionally, an eight-green/eight-red system is in place to show active channels with their associated channel issues respectively.

Technical Description of 140ARI03010C:

This model 140ARI03010C boasts a low power consumption of merely 1 watt while also adhering to the standard module format. This device uses an accurate temperature probe to produce up to 2.5 mA currents for analog inputs.

The 140ARI03010C model provides reliable channel isolation through 300 Vrms AC while offering an update time of 1200 ms for 3-wire applications. In addition to 9 input words addressing requirements, this powerhouse offers 13 bits resolution on its analog inputs.

This Analog RTD Input 8 Channel module offers precise temperature monitoring capabilities, capable of processing signals from up to eight different 2-, 3- and 4-wire sensors. These readings are seamlessly communicated with the Quantum CPU for accurate data interpretation.

The module (140ARI03010C) requires nine 16-bit words, with eight to accommodate data and one to indicate channel status. For optimal wiring configuration of the module, it is advisable to utilize wire sizes ranging from 20 AWG to 1 or 2 -14/16 AWG..

This highly accurate model boasts an absolute accuracy error of 0.1 degrees Celsius and a linearity error within +/-0.01% of full scale while weighing just 0.3 kilograms. It also efficiently draws 200 mA from the bus current for optimum performance.

The 140ARI03010C model's accuracy levels off at a mere 0.5 degree centigrade variance from the expected 25°C, with an impressive protection rating of 1780 V AC for up to one full minute across the 47-63 Hz frequency range.

Environmental Conditions:

The 140ARI03010C model must be used within a temperature range of 0 to 60°C and stored at temperatures between -40 and 85°C in an environment with no more than 95% relative humidity. The model can operate at peak efficiency even when placed as high up as 5000 meters of altitude.

This product prioritizes environmental safety, adhering to EU RoHS standards, and being completely mercury-free. Utilizing a designated waste collection site is essential.

General Instructions for the Model:

For the safety of operators, it is critical to ensure any machinery used has proper point-of-operation guarding. Unprotected equipment can lead to hazardous situations and cause serious harm or injury. Qualified personnel should be the only ones to install, operate, service, and maintain this model. The company is not liable for any adverse outcomes resulting from its use.

A range warning is immediately communicated When a channel input rises beyond the set rated value. If the conditions deteriorate and exceed this parameter by over 2.34%, an out-of-range bit will activate to notify users of potential danger. If a cable in a circuit is damaged or broken, the event will still happen.

Automation is key to efficiently controlling industrial processes. This model 140ARI03010C  offers flexibility in adapting for each application, with factors such as control function, level of protection, and other specifications being taken into account accordingly.
