TECHNICAL SPECIFICATIONS

Schneider Electric 140CPS11100

This Modicon Quantum's standalone power supply module 140CPS11100 provides a dependable energy source for any automation need. Quantum is an advanced system with digital processing capabilities tailored to deliver real-time control for industrial and manufacturing settings. The modular architecture design allows for easy expansion.

Technical Description of 140CPS11100:

With a wide input voltage range from 120 to 230 V AC and adjustable frequency between 47 to 63 Hz, the model 140CPS11100 allows for versatile power utilization. The current output is 200 mA at higher voltages (230 V) up to 400 mA when operating on lower powers of 115 V.

The 140CPS11100 model's 50 VA rated power requires a 1.5 A fuse, while the start-up inrush current is 10 A at 230 V and 20 A at 115 V, respectively.

The model 140CPS11100 offers incredibly low harmonic distortion, below 10% of the fundamental rms value. It can output an impressive 5.1 V DC with a maximum current draw of 3 A - all from a standalone unit.

This standalone power supply module offers superior protection with its internal output overvoltage and overload security, indicated by a single green LED for confirmation. The product weighs 0.65 kilograms and has been certified to meet UL and CE safety standards, ensuring high-quality control.

Ambient Conditions for the Model:

The model 140CPS11100 performs optimally within a temperature range of 0-60 degrees Celsius and an altitude ceiling of up to 5,000 meters above sea level.

For the model power supply module 140CPS11100 to function at its best, it requires maintenance within a temperature range of -40 to 85 degrees centigrade, and it is important to ensure that the relative humidity levels do not exceed 95 percent.

The product 140CPS11100 should be responsibly disposed of through proper waste collection channels to remain compliant with the EU RoHS Directive, as it is free from mercury.

Start-Up and Testing Instructions:

To ensure the proper functioning of module 140CPS11100, qualified personnel should conduct a start-up test before regular use. To ensure proper functioning, scheduling a thorough check and allocating enough time for its complete verification is crucial.

Please ensure you have completed all setup processes and removed any temporary restraints used for shipping from component devices before starting operational tests. Additionally, take care to remove tools, meters, and debris from the test model.

Operation and Adjustment Instructions:

Even if designed and manufactured with the utmost care, any given equipment model can be hazardous to operate should certain user protocols not be followed. User safety must always remain a priority when handling such tools.

Malfunctioning equipment can lead to unsafe or inadequate performance. Always heed the manufacturer's guidance when making adjustments to ensure proper functioning.

To ensure proper utilization of adjustments, personnel must be thoroughly knowledgeable in the functions and operations of equipment manufacturer instructions and machinery used with electrical devices.

Standard Safety Information:

This model 140CPS11100 provides superior control for various industrial processes. No matter the complexity or specific requirements, the automation equipment can be tailored to meet any need - from stringent protection protocols and government regulations to production methods optimized under challenging conditions.

Operating machinery without effective point-of-operation guarding can be hazardous, exposing the operator to potential severe harm. Before using your machine, ensure its safety to ensure the best possible safety measures are in place.
