TECHNICAL SPECIFICATIONS

Schneider Electric 140CPU65150

Schneider Electric has crafted this powerful CPU module 140CPU65150, capable of tackling many tasks and applications. This intricate model houses two local racks and 63 distributed I/O stations. This system can meet all requirements with time stamping, serial link, high-speed interrupt inputs, and counter capabilities for specific applications.

Technical Description of 140CPU65150:

Equipped with a high-performance ethernet router, this model 140CPU65150 has been optimized for rapid task completion at 0.2 ms overhead and 1 ms master latency while also providing visual feedback via two LEDs - green indicating network activity and red alerting of collision events.

The Unity Processor 140CPU65150 CPU module packs a powerful punch, boasting a maximum ladder logic capacity of 31 K words and discrete input/output capacities of over 30K each.

The model 140CPU65150 boasts an expansive analog I/O capacity of 500 inputs and outputs, plus six optional modules, including Ethernet, Modbus Plus, Profibus DP ad Sy/Max.

This impressive 140CPU65150 CPU module has an expansive 7168 kb of expandable RAM, allowing powerful programming software. With a blazingly fast 166 Mhz clock frequency and 768 Kb internal RAM in addition to the PCMCIA card, this model is built for speed with a current bus requirement of 2160 mA.

This 140CPU65150 model features three electrical connections for optimal performance. A SUB-D 9 female connector links the model to a Modbus Plus network, while an RJ45 connection allows it to work with Ethernet networks. There is also an RJ45 port enabling communication through the Modbus bus.

LED and Key Switch Specifications and Information:

The CPU sports a 2-line by 16-character LCD display with an adjustable backlight setting and contrast, providing users with enhanced customizability. Moreover, its user interface is automated for maximum efficiency and has LED lights illuminating when you press new keys or if an error message displays on the screen.

The backlight is designed to turn off after 5 minutes of inactivity but will remain on for any error messages appearing on the LCD screen.

The 140CPU65150 model's key switch provides a layer of security, protecting memory and system integrity. Offering two positions - Locked or Unlocked - the OS Executive is responsible for detecting its status alone; the loader portion of firmware cannot read it.

The CPU module provides sophisticated system menus for operators to effortlessly initiate and manage PLC operations like starting or stopping and display any necessary module parameters such as communications settings.

Operating and Storage Ambient Conditions:

The model must be used at a temperature range of 0 - 60°C and stored in an environment with temperatures between -40 - 85°C, while humidity levels should not exceed 95%. To ensure peak performance, keep the model in an area free from moisture and shielded from direct sunlight.

Standard Safety Precautions:

This model 140CPU65150 offers precise control of a wide range of industrial processes - however, use it with appropriate safeguarding measures in place for the operator's safety. Operating machinery without protective point-of-operation guards can result in potentially serious injury to those using it.

Only experienced and trained personnel should install, operate, service, and maintain the model 140CPU65150 for optimal performance. The company makes no guarantees concerning the effects or implications of using this analog module. Customers should be aware that any action taken is at their own risk.
