Schneider Electric 140CRP93200

The Schneider Electric 140CRP93200 is a high-performance Modicon Quantum RIO (Remote Input/Output) head-end adaptor module. It has two connectors with redundant cable support, which provides increased dependability and flexibility in industrial automation applications.

Technical Specs:

Two connections indicate that the module contains two physical ports or interfaces that allow cables to be connected. These connectors allow the module to be connected to remote I/O drops or other devices in the automation system.

The redundant cable support refers to the module's ability to employ duplicate or backup cables for data transmission. Redundancy is an important feature in industrial applications because it allows uninterrupted functioning even if a cable fails or is disconnected.

The bus current required for this module is 750 mA, and its power dissipation is 3.8 W. The dynamic range of the module is 35 dB, and its data transfer frequency is 1.544 MHz.

Its isolation voltage of 500 V DC indicates that it is intended to give a high level of electrical isolation and protection. It enables safe and dependable operation in situations with changing voltage potentials or when electrical isolation is necessary to ensure signal integrity and avoid electrical damage or risks.

The 140CRP93200 is compatible with Symax and Quantum series systems. It can be seamlessly integrated and used with Symax (any mix) and Quantum 200, 500, and 800 series equipment.

Space Requirements for Installation of the Module:

To be securely attached, the 140CRP93200 module requires a suitable mounting surface or panel. When deciding where to place the module, keep its physical size and weight in mind. Make sure there is enough room for the module to be firmly secured, as well as any necessary wiring connections.

Consider how much room is needed to route the cables that connect the module to other devices, such as the Modicon Quantum PLC and remote I/O drops. Plan for proper cable management in order to keep cables organized and avoid interference with other devices.

Take into account any environmental concerns that may have an impact on the installation. If the module is installed in a harsh or corrosive environment, further protection measures or enclosures may be required to protect the module.

Ideal Standards:

The Schneider Electric 140CRP93200 follows several standards to perform efficiently. By adhering to the following standards, the product demonstrates its compliance with rigorous safety regulations, ensuring that it meets the necessary safety standards for installation and use in industrial control applications.

The UL 508 safety standard applies to industrial control equipment, including control panels. It guarantees that the equipment complies with certain electrical safety criteria, such as adequate wiring, grounding, and electrical hazard protection. UL 508 compliance ensures that the product has been tested and evaluated to fulfill certain safety criteria.

A Canadian standard for industrial control equipment is CSA C22.2 No 142. It addresses the same safety concerns as UL 508 and confirms that the product fulfills Canadian safety standards. Compliance with CSA C22.2 No 142 means that the product has been tested and certified to fulfill Canadian safety standards.

CUL is an abbreviation for Certified Underwriters Laboratories. It denotes that Underwriters Laboratories, an independent safety consulting and certification firm, has certified the product. The CUL mark indicates that the product has met Underwriters Laboratories' safety regulations and standards and is regarded safe for use in the United States and Canada.
