Schneider Electric 140DAO85300

Schneider Electric 140Dao85300

Schneider Electric 140DAO85300

Regular price
$359.00
Sale price
$359.00
We currently have 1 in stock.
Checkmark

In stock - Ships Today

Checkmark

Eligible for Next Day Delivery

Checkmark

Ships From Our North Carolina Warehouse

Eligible for Next Day Delivery All Parts Come with 24 Month Warranty New, Refurbished and Repairs Available


We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.


All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.


Payment options

We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.

Credit Terms

We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.

Description

  • 140DAO85300
  • DISCRETE OUTPUT MODULE
  • 10-253 VAC
  • 300 VRMS FOR 10S AC MAX OUTPUT
  • 4 GROUPS OF 8 CHANNELS
  • 400 VRMS 1CYCLE AC MAX OUTPUT
  • 47-63 HZ
  • 16 AMP RMS PER MODULE MAX LOAD CURRENT
  • 4 AMP RMS PER GROUP MAX LOAD CURRENT

All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.

Buying Options
Buying Options

All products are covered by Industrial Automation Co.'s 2-Year Warranty.

Condition SKU Price Warranty Availability Quantity Purchase
New 140DAO85300-FS $359.00 USD 2 Year Extended Warranty 1 In Stock in US!
Quick Repairs and Great Service

Send in your item for a free evaluation and repair quote. Use our RMA form or email a repair request to service@iac.us.com , and we will contact you to assess your situation and offer shipping information.

Quick Search

TECHNICAL SPECIFICATIONS

Schneider Electric 140DAO85300

The Schneider Electric 140DAO85300 module is a Modicon Quantum series discrete output module. It is intended for industrial automation applications to give dependable and accurate control over discrete output signals. To satisfy the expectations of current control systems, this module provides enhanced features and capabilities.

Technical Specifications of the Module:

The module provides various configuration options for each output channel, allowing them to be set as relay outputs or solid-state outputs individually. Because of its adaptability, the module can suit a variety of load types and application needs.

The relay outputs are capable of handling both AC and DC voltages, whilst the solid-state outputs are intended for low-voltage DC loads.

The 140DAO85300 module simplifies setup and communication between the module and the controller by easily integrating with Modicon Quantum programmable logic controllers (PLCs) and automation systems. It communicates with the PLC via the backplane communication bus, which ensures a dependable and efficient data transmission.

The module's hot-swapping capability is one of its most remarkable features. This means that while the system is powered on, the module can be introduced or removed from the rack without interfering with the operation of other modules or the control system.

This feature streamlines maintenance processes and allows for system expansion because modules can be swapped or added without shutting down the system.

Troubleshooting and Preventive Maintenance:

Troubleshooting and preventive maintenance are required to keep the Schneider Electric 140DAO85300 module running at peak performance and dependability. It is critical to use the module's diagnostic capabilities to efficiently troubleshoot any difficulties that may develop.

The module is intended to offer useful information about each output channel's status and performance. By monitoring these diagnostics on a regular basis, one can rapidly identify and address any potential issues, minimizing downtime and preventing system breakdowns.

It is critical to have access to the product documentation offered by Schneider Electric to ensure effective troubleshooting. User manuals, technical specifications, and troubleshooting guides provide useful information on the module's operation and common problems.

This information will help to comprehend the module's functions, evaluate diagnostic indicators, and follow recommended troubleshooting methods.

Regular checks of the module are also necessary for detecting any problems. Visually inspect all connections to ensure they are secure, wires are not broken, and the module is appropriately situated in its rack or container.

Overheating symptoms, such as excessive heat or strange odors, can signal underlying issues. Routine inspections allow you to identify and handle problems before they become serious problems.

Another key part of preventive maintenance is keeping the module's firmware up to date. Check for Schneider Electric firmware updates and confirm the module is running the most recent version. Firmware upgrades frequently include bug fixes, performance enhancements, and increased functionality, all of which can improve the module's stability and performance.

A regular maintenance program is essential for preventive maintenance. The cleaning, inspection, and testing of the module should be included in this schedule.

Clean the module on a regular basis, removing dust and debris that can impede its performance. Examine the module for evidence of wear, loose connections, or other irregularities. Test the module's functionality and check that it is running within specs.

Training in troubleshooting and maintenance techniques is beneficial for dealing with module difficulties successfully. Consider getting suitable training or consulting with competent professionals.
