Schneider Electric ATV630D11M3

Among the Altivar Process ATV600 series variable-speed drives, Schneider Electric's ATV630D11M3 stands out for its versatility and durability. It improves industrial settings' motor control and energy efficiency and is designed for utility and process applications.

This drive is versatile since it can accommodate both synchronous and asynchronous motors. Thanks to its sophisticated features and dependable performance, the model is a great way to maximize system efficiency and optimize motor operations.

Technical Specifications:

ATV630D11M3 AC power range is 50 € “60 Hz, and its rated voltage is 200 € “240 V. It supports its 11 kW normal-duty and 7.5 kW heavy-duty motors. The maximum horsepower for ordinary duty is 15 hp, and for heavy-duty, it is 10 hp. Line currents vary by duty type and voltage from 39.3 A to 27.2 A. The drive generates 13.7 kVA under normal load and 9.6 kVA under severe load at 240 V.

Derating factors can change the ATV630D11M3's forced convection cooling system to 2 € “12 kHz. Its extensive profiles, including optimized torque mode and variable torque standard, regulate synchronous and asynchronous motors. The device incorporates SIL 3-rated safe torque off for further security.

The compact ATV630D11M3 is 211 mm wide, 546 mm tall, and 232 mm deep. Its 13.8 kg weight makes installation and handling easy. The enclosure's wall-mount construction allows multiple mounting options.

Features and Connectivity:

This drive supports Ethernet, Modbus Serial, and Modbus TCP, among other protocols. It also supports PROFINET, DeviceNet, Profibus DP V1, and CANopen communication modules. Many digital and analog I/O extension modules allow this drive to be used in many applications.

The ATV630D11M3 has various discrete and analog input/output connectors for flexibility. It can receive voltage or current signals via its three analog and eight discrete inputs. It features three relay outputs, two of which are analog and other settings and protections.

Protection and Safety Features:

The ATV630D11M3 has multiple safety features to guarantee safe and dependable operation. These safeguards cover motor phase breaks, overcurrent, thermal overload, and short circuits. You may set the acceleration and deceleration ramps on the device to anywhere from 0.01 to 9999 seconds, and it will handle motor slip adjustment automatically.

For mission-critical applications, the drive will perform to UL type 1 and IEC requirements. In addition, a thermal protection device protects the drive and motor from overheating.

Applications and Certifications:

Applications in the water and wastewater, oil and gas, and food and beverage processing industries are just a few of the many that the ATV630D11M3 excels. Improving process efficiency as a whole, it can regulate pumps, compressors, fans, and conveyors with ease. This drive is certified by DNV-GL, UL, CSA, and ATEX for zone 2/22, so you can be sure it meets all these international standards.

Frequently Asked Questions:

What types of motor control configurations does the ATV630D11M3 support?

Both the optimized torque mode and the variable torque standard motor control profiles are compatible with the ATV630D11M3. Asynchronous and synchronous motors alike can be controlled precisely and operated efficiently in this way.

On the ATV630D11M3, how many discrete inputs and outputs are available?

There are a total of eight individual inputs and three outputs on the ATV630D11M3. These inputs and outputs make it easy to integrate with different control systems and give flexibility.

What is the maximum horsepower rating and motor power for heavy-duty operations?

For tough jobs, rely on the ATV630D11M3's 7.5 kW motor and maximum horsepower rating of 10 hp. It is engineered to efficiently manage rigorous industrial applications.
