Schneider Electric ATV630D15N4
Schneider Electric ATV630D15N4
One reliable and adaptable variable-speed drive from Schneider Electric's ATV600 series is the ATV630D15N4 model. Asynchronous and synchronous motors are both catered to in its design, which is ideal for industrial and utility applications. Improving efficiency and control in industrial settings is made easy with this drive's dependable performance, even in the most demanding circumstances.
Technical Specifications:
The ATV630D15N4 from Schneider Electric can run on a voltage range of 380 to 480 V and a frequency range of 50 to 60 Hz, with a fluctuation of ±5%. To further guarantee low electromagnetic interference, it has an integrated EMC filter that complies with EN/IEC 61800-3 categories C2 and C3. The drive's IP21 rating, which is in accordance with IEC 60529, protects it from solid objects and moisture.
The ATV630D15N4 is versatile in its installation options because it is wall-mounted. You can efficiently use space by mounting it alone or side by side with other modules. To ensure the drive gets enough air and stays cool, you need to leave 100 mm of space on both sides. The cooling system of the ATV630D15N4 is controlled by forced convection, which allows it to work at its best in all kinds of situations.
Regular and heavy duty can handle transient currents up to 34.9 A for 60 seconds and 35.3 A, respectively. This drive controls motor torque with optimal, variable, and constant modes. It can perform at -10 degrees without deterioration, making the ATV630D15N4 ideal for many climes. Installation at elevations up to 4800 meters reduces current derating by 1% for 100 meters above 1000 meters.
Small and lightweight, the drive weighs 13.6 kg and measures 211 mm wide, 546 mm tall, and 232 mm deep. Its strong construction ensures industrial reliability and longevity.
Communication and Connectivity:
The ATV630D15N4 supports Ethernet, Modbus serial, and Modbus TCP. It has many CANopen, DeviceNet, PROFINET, and Profibus DP V1 ports. These options' easy integration into various industrial networks ensures operational efficiency.
The drive has three voltage- or current-configurable analogue inputs for control and monitoring. Eight inputs can accept pulses up to 30 kilohertz. Software may set the analogue outputs to output voltage or current (0-20 mA), providing you excellent control flexibility.
Safety and Protection:
The ATV630D15N4 has multiple safeguards to keep the engine and drivetrain safe. An additional safeguard against unintentional motor starts is the STO (Safe Torque Off) feature, which is SIL 3 certified. The drive comes with a number of safety features, including those that prevent the motor and the drive from overheating, short circuits, and overcurrent.
With a maximum cycle life of 100,000, the drive's relay outputs can be set up to perform various logic operations. Reliable performance in control applications is ensured by these outputs, which can handle switching currents up to 3 A at 250 V AC or 30 V DC for resistive loads and up to 2 A for inductive loads.
Frequently Asked Questions:
What are the communication protocols supported by the ATV630D15N4?
The ATV630D15N4 supports Ethernet, Modbus serial, and Modbus TCP communication protocols. These options enable seamless integration into various industrial networks.
How many analog inputs and discrete inputs does the ATV630D15N4 have?
The ATV630D15N4 features three analog inputs and eight discrete inputs, all of which are programmable. This flexibility allows for precise control and monitoring of various processes.
What safety functions and certifications does the ATV630D15N4 include?
The ATV630D15N4 includes Safe Torque Off functionality with SIL 3 certification. This provides a critical safety layer, ensuring secure operation in industrial environments.
Product Specifications Table:
| Attribute | Specification |
|---|---|
| Product Series | Altivar Process ATV600 |
| Product Type | Variable Speed Drive |
| Cooling Method | Forced Convection |
| IP Rating | IP21 |
| Communication Protocols | Ethernet, Modbus Serial, Modbus TCP |
| Analog Inputs | 3 |
| Discrete Inputs | 8 |
| Safety Function | Safe Torque Off (STO) SIL 3 |
| Mounting Options | Wall Mount |
| Dimensions (WxHxD) | 211 mm x 546 mm x 232 mm |
We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Payment options
We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.
Credit Terms
We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.
Description
Schneider Electric ATV630D15N4
One reliable and adaptable variable-speed drive from Schneider Electric's ATV600 series is the ATV630D15N4 model. Asynchronous and synchronous motors are both catered to in its design, which is ideal for industrial and utility applications. Improving efficiency and control in industrial settings is made easy with this drive's dependable performance, even in the most demanding circumstances.
Technical Specifications:
The ATV630D15N4 from Schneider Electric can run on a voltage range of 380 to 480 V and a frequency range of 50 to 60 Hz, with a fluctuation of ±5%. To further guarantee low electromagnetic interference, it has an integrated EMC filter that complies with EN/IEC 61800-3 categories C2 and C3. The drive's IP21 rating, which is in accordance with IEC 60529, protects it from solid objects and moisture.
The ATV630D15N4 is versatile in its installation options because it is wall-mounted. You can efficiently use space by mounting it alone or side by side with other modules. To ensure the drive gets enough air and stays cool, you need to leave 100 mm of space on both sides. The cooling system of the ATV630D15N4 is controlled by forced convection, which allows it to work at its best in all kinds of situations.
Regular and heavy duty can handle transient currents up to 34.9 A for 60 seconds and 35.3 A, respectively. This drive controls motor torque with optimal, variable, and constant modes. It can perform at -10 degrees without deterioration, making the ATV630D15N4 ideal for many climes. Installation at elevations up to 4800 meters reduces current derating by 1% for 100 meters above 1000 meters.
Small and lightweight, the drive weighs 13.6 kg and measures 211 mm wide, 546 mm tall, and 232 mm deep. Its strong construction ensures industrial reliability and longevity.
Communication and Connectivity:
The ATV630D15N4 supports Ethernet, Modbus serial, and Modbus TCP. It has many CANopen, DeviceNet, PROFINET, and Profibus DP V1 ports. These options' easy integration into various industrial networks ensures operational efficiency.
The drive has three voltage- or current-configurable analogue inputs for control and monitoring. Eight inputs can accept pulses up to 30 kilohertz. Software may set the analogue outputs to output voltage or current (0-20 mA), providing you excellent control flexibility.
Safety and Protection:
The ATV630D15N4 has multiple safeguards to keep the engine and drivetrain safe. An additional safeguard against unintentional motor starts is the STO (Safe Torque Off) feature, which is SIL 3 certified. The drive comes with a number of safety features, including those that prevent the motor and the drive from overheating, short circuits, and overcurrent.
With a maximum cycle life of 100,000, the drive's relay outputs can be set up to perform various logic operations. Reliable performance in control applications is ensured by these outputs, which can handle switching currents up to 3 A at 250 V AC or 30 V DC for resistive loads and up to 2 A for inductive loads.
Frequently Asked Questions:
What are the communication protocols supported by the ATV630D15N4?
The ATV630D15N4 supports Ethernet, Modbus serial, and Modbus TCP communication protocols. These options enable seamless integration into various industrial networks.
How many analog inputs and discrete inputs does the ATV630D15N4 have?
The ATV630D15N4 features three analog inputs and eight discrete inputs, all of which are programmable. This flexibility allows for precise control and monitoring of various processes.
What safety functions and certifications does the ATV630D15N4 include?
The ATV630D15N4 includes Safe Torque Off functionality with SIL 3 certification. This provides a critical safety layer, ensuring secure operation in industrial environments.
Product Specifications Table:
| Attribute | Specification |
|---|---|
| Product Series | Altivar Process ATV600 |
| Product Type | Variable Speed Drive |
| Cooling Method | Forced Convection |
| IP Rating | IP21 |
| Communication Protocols | Ethernet, Modbus Serial, Modbus TCP |
| Analog Inputs | 3 |
| Discrete Inputs | 8 |
| Safety Function | Safe Torque Off (STO) SIL 3 |
| Mounting Options | Wall Mount |
| Dimensions (WxHxD) | 211 mm x 546 mm x 232 mm |
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
