Schneider Electric ATV630D22N4
Schneider Electric ATV630D22N4
The ATV630D22N4 variable-speed drive is from Schneider Electric's ATV600 series. Featuring state-of-the-art motor control capabilities for synchronous and asynchronous motors, it is engineered to optimize industrial processes and utilities. A dependable option for a variety of industrial demands, this drive incorporates sturdy characteristics and offers a diverse range of applications.
Technical Specifications:
The ATV630D22N4 can run on 50 to 60 Hz power with a rated voltage range of 380 to 480V. Under typical operating conditions, this type can handle line currents up to 39.6A at 380V and 34.4A at 480V. There is a range of 34.1A to 29.9A for heavy-duty applications.
For standard-duty applications, the continuous output current is 46.3A at 4 kHz, while for heavy-duty applications, it drops to 39.2A at the same frequency. Additionally, it has a maximum transient current of 58.8A under heavy-duty settings and 50.9A under regular-duty conditions for 60 seconds.
Adhering to EN/IEC 61800-3 category C2 for cables up to 50 meters and category C3 for cables up to 150 meters, it offers efficient performance with an incorporated EMC filter. In accordance with UL type 1 and IEC 61800-5-1, the drive has an IP21 protection grade.
The drive offers optimum torque mode, constant torque standard, and variable torque standard for asynchronous motors. It supports synchronous reluctance and permanent magnet motor control profiles. Output frequencies range from 0.1 to 500 Hz.
ATV630D22N4 can be wall-mounted vertically or side-by-side. Small at 211 mm broad, 546 mm tall, and 232 mm deep, it weighs 14.3 kg. Without derating, the device can operate from -15°C to 50°C; with derating, it can reach 60°C. At altitudes up to 1000 meters, it works effectively, but higher ones require a derating factor.
68W is dissipated by natural convection at 380V and 4kHz, while 505W is dissipated through forced convection, demonstrating the unit's excellent cooling mechanism. In order to meet the requirements of 86/188/EEC, the noise level is kept at a reasonable 59.5 dB.
Communication and Input/Output Options:
Modbus TCP, Ethernet, and serial are among the ATV630D22N4's connectivity options. It supports optional Profibus DP V1, PROFINET, DeviceNet, and CANopen communication modules, making it more versatile in industrial situations.
The ATV630D22N4 offers a safe torque off, overcurrent and overvoltage protection, and external drive and motor thermal protection.
Environmental and Compliance Features:
Complying with a number of EMC requirements, including IEC 61000-4-2 for conducted radio-frequency immunity and an operating humidity range of 5% to 95% without condensation, the ATV630D22N4 is designed to endure severe industrial settings. According to EN/IEC 61800-5-1, it satisfies pollution degree 2 criteria as well. This variable speed drive meets all international safety and performance requirements thanks to its certifications from ATEX zone 2/22, CSA, TÃV, DNV-GL, and UL.
Frequently Asked Questions:
What are the ATV630D22N4's deceleration capabilities and output voltage?
An output voltage of up to the supply voltage is provided by the ATV630D22N4. Additionally, it is compatible with DC injection braking to a stop.
Could the ATV630D22N4 be utilized with an external power supply for digital inputs, and if so, what is the range?
An external power source ranging from 19 to 30 V DC can be used with the digital inputs on the ATV630D22N4. For your safety, it has short-circuit protection as well.
What is the switching current of the ATV630D22N4's relay outputs, and how many are there?
With three relay outputs, the ATV630D22N4 can handle switching currents up to three amps at 250 volts alternating current. You can use these relay outputs with inductive or resistive loads.
Product Specifications Table:
| Attributes | Specification |
|---|---|
| Rated Supply Voltage | 380-480 V |
| Frequency | 50-60 Hz |
| Protection Rating | IP21 |
| Continuous Output Current | 46.3 A (normal duty), 39.2 A (heavy duty) |
| Output Frequency | 0.1-500 Hz |
| Analog Inputs | 3, configurable voltage (0-10V), current (0-20mA) |
| Analog Outputs | 2, configurable voltage (0-10V), current (0-20mA) |
| Relay Outputs | 3, 3A at 250V AC |
| Operating Temperature | -15 to 50°C (without derating) |
| Communication Ports | Modbus TCP, Ethernet, Modbus serial |
