Schneider Electric ATV630D55N4
Schneider Electric ATV630D55N4
The ATV630D55N4 from Schneider Electric's Altivar Process 630 line of variable-speed drives is designed for industrial automation. A variety of features improve energy economy and process optimization, making this product perfect for regulating synchronous and asynchronous motors.
Technical Specifications:
With its wide voltage range of 380 to 480 volts, the ATV630D55N4 is suitable for various industrial settings. The fact that it works with both synchronous and asynchronous motors broadens its potential uses. With a substantial 55 kW standard duty rating and 45 kW (60 hp) heavy-duty rating, this device guarantees powerful performance.
To further guarantee low electromagnetic interference, the device incorporates an EMC filter that complies with EN/IEC 61800-3 category C3. The drive's forced convection cooling technique ensures effective thermal management even in extreme environments. This guarantees long-term durability and dependable performance.
The ATV630D55N4 can handle 50–60 Hz supply frequencies with a -5% to +5% tolerance. Line current capacity is high, with a maximum of 97.2 A and 84.2 A for normal operation. It efficiently manages 81.4 A and 71.8 A, which is ideal for heavy-duty applications.
The broad control profiles of the ATV630D55N4 stand out. It offers optimum torque mode for synchronous motors and standard control with constant and variable torque for asynchronous motors. A broad output frequency range of 0.1 to 500 Hz allows the drive to accurately operate motors in many applications.
Ambient Operating Conditions:
With its IP21 protection classification, the ATV630D55N4 can withstand dust and water drops that fall from a height, making it ideal for use in demanding industrial settings. This drive is designed to work reliably in a wide range of temperatures, as it can function between 5 and 122 °F without derating and up to 140 °F with a derating factor.
The drive's resilience to vibration and shock proves its sturdy build. By IEC 60068-2 requirements, it can endure shocks of up to 15 gn for 11 ms and vibrations of 1.5 mm peak-to-peak. The drive's small size—290 mm wide, 922 mm tall, and 323 mm deep—and light weight of 56.5 kg make it easy to install and handle.
Sustainability and Compliance:
Schneider Electric has made sure the ATV630D55N4 is eco-friendly. Because it complies with all of the most recent environmental standards, it bears the Green Premium designation. The drive carries a REACh declaration and complies with RoHS regulations, demonstrating its eco-friendliness.
The product's worldwide applicability and dependability are guaranteed by its adherence to multiple international standards, such as UL 508C, EN/IEC 61800-3, and IEC 61000-3-12. Notable among its many safety features are protections against overcurrent and motor and drive thermal failure.
Frequently Asked Questions:
Is it possible for the ATV630D55N4 to accommodate various communication protocols and cooling methods?
The ATV630D55N4 is compatible with Modbus and Ethernet serial communication protocols and uses forced convection cooling. This ensures that heat is dissipated efficiently and that it can be easily integrated into industrial networks.
What is the maximal transient current and motor power rating of the ATV630D55N4?
<>Motor power ratings for the ATV630D55N4 range from 45 kW for severe duty to 55 kW for moderate use. Under normal operating conditions, it can sustain a transient current of up to 116.6 A for a duration of 60 seconds.In what manner does the ATV630D55N4 guarantee the safety and precision of motor control?
With SIL 3 safety and a display unit frequency resolution of 0.1 Hz, the ATV630D55N4 is a top-tier ATV. This guarantees top-notch safety while providing exact control over the motor.
Product Specifications Table:
| Attribute | Specification |
|---|---|
| Manufacturer | Schneider Electric |
| Power Rating | 55 kW |
| Voltage Range | 380-480 V |
| IP Protection | IP21 |
| Cooling Method | Forced Convection |
| Communication Protocols | Ethernet, Modbus Serial |
| Max Transient Current | 116.6 A (60 s normal duty) |
| Frequency Resolution | 0.1 Hz (display unit) |
| Safety Function | STO (Safe Torque Off) SIL 3 |
| Dimensions (W x H x D) | 290 mm x 922 mm x 323 mm |
| Weight | 56.5 kg |
