Schneider Electric ATV630D75N4
Schneider Electric ATV630D75N4
The Schneider Electric ATV630D75N4 is a high-performance variable speed drive for process and utility applications. This drive is part of the Altivar Process series, known for its energy efficiency, robust design, and versatile control capabilities. Ideal for asynchronous and synchronous motors, it offers advanced features to enhance operational reliability and efficiency.
Technical Specifications:
The ATV630D75N4 can handle 50–60 Hz with a 380–480V supply voltage. Intended for various industrial tasks, it can accommodate 75 kW regular duty and 55 kW heavy duty motors. Light duty maxes at 100 horsepower, and heavy duty at 75.
This drive has EN/IEC 61800-3 category C3 EMC filters to reduce electromagnetic interference. IP21 protection according to IEC 60529 and UL type 1 according to UL 508C indicate strong environmental resistance.
Its maximum line currents of 131.3 A at 380 V and 112.7 A at 480 V in normal operation make the ATV630D75N4 ideal for demanding applications. Regular duty provides 145 A at 2.5 kHz output current and stable performance.
The Ethernet, Modbus serial, and Modbus TCP communication protocols make integrating the ATV630D75N4 into industrial networks easy. You can enhance connectivity with its many option card slots for communication modules like Profibus DP V1, PROFINET, and DeviceNet.
Discrete input logic on the drive allows for flexible speed control with 16 preset rates. Ethernet and 2-wire RS 485 comprise the physical interface, offering reliable and versatile networking choices.
The drive's dimensions are 11.42 inches wide, 36.30 inches tall, and 12.72 inches deep, weighing 127.87 pounds. With these dimensions, installation is guaranteed to be stable and seamless with current configurations.
Advanced Features:
You can optimize the device's performance to your liking by adjusting the switching frequency, which is configurable from 2.5 to 8 kHz. In addition, its nominal switching frequency is 2.5 kHz, making it ideal for use in high-pressure industrial settings.
Compliance with international safety and quality standards is ensured by ATV630D75N4's certifications and standards, which include CSA, ATEX zone 2/22, TÜV, UL, and DNV-GL. It is ideal for settings with minimal background noise, thanks to its 62.4 dB noise rating.
Connectivity and Control:
The ATV630D75N4 has four dual-color LEDs for the state of the communication module and three for local diagnostics and embedded communication. These help with control and diagnostics. Reliable functioning with 24 V DC within a voltage range of 19 to 30 V is ensured by its support for an external supply for digital inputs.
The drive has three programmable relays that handle sequence and fault operations; each relay can withstand up to 100,000 cycles. The switching currents for resistive and inductive loads are different, and these relays handle a range of voltages, including 250 V AC and 30 V DC.
Frequently Asked Questions:
How does the Schneider Electric ATV630D75N4 manage load and motor control?
Both constant and variable torque motor control profiles are compatible with the ATV630D75N4. In addition, it has motor slip compensation that changes automatically under different loads.
What input configurations and communication protocols are supported by the ATV630D75N4?
Ethernet and Modbus TCP are two protocols that the ATV630D75N4 can communicate with. All sorts of control choices are at your fingertips, and it has eight discrete inputs and three analog inputs.
What is the ATV630D75N4's decibel level and operating temperature range?
Without derating, the ATV630D75N4 runs efficiently from 5 to 122°F. Designed for quiet settings, the noise level stays at a respectable 62.4 dB.
Product Specifications Table:
| Attribute | Specification |
|---|---|
| Product Series | Altivar Process ATV600 |
| Rated Supply Voltage | 380-480 V |
| Power Rating | 75 kW (normal duty), 55 kW (heavy duty) |
| Maximum Horse Power | 100 hp (normal duty), 75 hp (heavy duty) |
| Switching Frequency | 2.5-8 kHz adjustable |
| Communication Protocols | Ethernet, Modbus TCP |
| Protection Rating | IP21, UL type 1 |
| Continuous Output Current | 145 A (normal duty), 106 A (heavy duty) |
| Operating Temperature | 5-122°F without derating |
| Noise Level | 62.4 dB |
