Schneider Electric ATV930D30N4

The Schneider Electric ATV930D30N4 is an advanced Variable Speed Drive engineered for powerful machines. This drive excels in managing asynchronous and synchronous motors. It boasts a versatile three-phase system and easy wall-mounted installation. The model has an integrated EMC filter and multiple communication protocol support, including Modbus serial and EtherNet/IP. Its compact design and comprehensive protection standards make it a reliable and efficient choice for various industrial needs.

Technical Specifications:

The Schneider Electric ATV930D30N4 Variable Speed Drive belongs to the Altivar Process ATV900 range. It is a standard version with a braking chopper. It operates on a three-phase system. The rated supply voltage for this drive ranges from 380 to 480 V with a tolerance of -15% to +10%.

The motor power is rated at 30.0 kW for normal duty and 22.0 kW for heavy-duty operations. The continuous output current is 61.5 A at 4 kHz for normal duty and 46.3 A at 4 kHz for heavy duty.

The degree of protection is IP21, meeting the UL type 1 standard. Discrete input logic includes 16 preset speeds, allowing for versatile operation. The drive's dimensions are 673 mm in height, 226 mm in width, and 274 mm in depth.

The net weight of the device is 28 kg (61.73 lbs.). The drive offers excellent motor performance and comprehensive control of any coupling type. The drive also supports a communication module for Ethernet Powerlink.

Key Features:

The Schneider Electric ATV930D30N4 supports multiple communication protocols, including Modbus serial, EtherNet/IP, and Modbus TCP. It is wall-mounted, ensuring easy installation in various environments. The drive features a slot A for various communication modules. The drive has slots for digital and analog I/O extension modules and output relay extension modules.

The ATV930D30N4 offers IP21 protection and complies with UL type 1 standards, providing adequate protection against dust and ingress of water. This makes it suitable for use in various environmental conditions within industrial settings. It also features an integrated braking chopper, which assists in dynamic braking operations.

Safe Installation:

Follow strict safety guidelines When installing the Schneider Electric ATV930D30N4 Variable Speed Drive. Only qualified personnel should handle the installation, maintenance, and operation. Disconnect all power sources, lock switches in the open position, label them "Do Not Turn On," and wait 15 minutes for DC bus capacitors to discharge. Verify the absence of voltage before starting.

Proper grounding is essential. Comply with local and national electrical codes, ensuring continuous and secure grounding. Use appropriate protective ground conductors and avoid looping ground cables. Use proper tools to prevent swinging or toppling. Use cables with at least 75 °C heat resistance for wiring, ensuring compliance with EMC requirements.

Frequently Asked Questions:

What is the noise level of the Schneider Electric ATV930D30N4 Variable Speed Drive?

The Schneider Electric ATV930D30N4 Variable Speed Drive has a noise level of 71.5 dB, compliant with the 86/188/EEC standard. This ensures that the drive operates within acceptable noise limits for industrial environments.

What are the vibration resistance specifications for the Schneider Electric ATV930D30N4?

The ATV930D30N4 Variable Speed Drive withstands vibrations of 1.5 mm peak to peak at 2-13 Hz and one gn at 13-200 Hz, per IEC 60068-2-6. These specifications confirm the drive's robust design, suitable for installations where vibration is a concern.

What is the shock resistance rating of the Schneider Electric ATV930D30N4 Variable Speed Drive?

The Schneider Electric ATV930D30N4 Variable Speed Drive can endure shock resistance of 15 gn for 11 ms, compliant with IEC 60068-2-27. This rating highlights the drive's ability to withstand sudden impacts, making it reliable in demanding applications.
