Yaskawa SGDH-50DE

The Yaskawa SGDH-50DE is a powerful Sigma II Series servo drive machine manufactured and marketed by Yaskawa Electric Corporation. It has precise motion control that is useful in many industrial applications. It has a self-tuning capability and offers a high-speed response with built-in compatibility with Yaskawa servo motors.

Technical Description:

The Yaskawa SGDH-50DE is an advanced servo drive belonging to the Sigma II series and offers high accuracy and high efficiency for industries. Yaskawa Electric Corporation manufactures it, and this model performs commendably in terms of the various attributes that support accurate control of motion. Because it supports a variety of servo motor types, the system is reliable for the majority of motor control applications.

Some features of the SGDH-50DE include the output power of 5kW with an input voltage range of 200-230V AC, meaning that it is perfect for use in medium and large applications. Further, it has a fast response frequency ranging from 100 to 1000 Hz, which means the positioning will be done efficiently and in the shortest time. Auto-tuning is provided on the drive, and it automatically adapts to the optimal configuration that you require.

Further, the self-protection function realizes overcurrent, overvoltage, and heating protection on SGDH-50DE, which improves operational security. The compact design is convenient for installation into control panels and makes the best utilization of limited space. The servo drive also has built-in communication interfaces for MECHATROLINK-II and others to ease integration for the latest systems. This makes it ideal for use in a harsh and rigorous industrial environment.

Attachments Specifications:

The Yaskawa SGDH-50DE servo drive has feedback cables and power cables used for the purpose of making sure that the connections are well-fixed and consequently more secure. It also supports multiple encoder types, such as incremental and absolute encoders, which enables the drive to provide position feedback information.

Further, the mounting brackets and terminal blocks help to make easy installation throughout the series and interconnection in control panels. It also has optional communication modules like MECHATROLINK-II and DeviceNet to enhance the connectivity of the machine.

Standard Safety Precautions:

While using the Yaskawa SGDH-50DE servo drive, it is essential to follow standard safety measures. It is necessary to make sure that it is well grounded to avoid shocks. Do not touch any of the internal parts of the drive while it is operating, as this may cause an accident. Make sure that electrical wiring is wired and adequately secured so as to avoid short circuits or damaging any electrical devices.

Ensure sufficient working conditions that include cooling and proper airflow since there are many cases of products overheating. Monitor and maintain the drive at regular intervals for desired levels of performance. Further, the overcurrent and overvoltage should be protected by incorporating fuses and circuit breakers. Thus, adherence to these measures ensures work safety and productivity in the future.

Frequently Asked Questions:

What is the power rating of the Yaskawa SGDH-50DE servo drive?

The Yaskawa SGDH-50DE servo drive has a power rating of 5.0 kW, suitable for medium to large-scale industrial applications.

What types of encoders are compatible with the SGDH-50DE?

The SGDH-50DE supports various encoder types, including incremental and absolute encoders, providing precise position feedback for enhanced control.

What communication protocols does the SGDH-50DE support?

The SGDH-50DE supports several communication protocols, including MECHATROLINK-II and DeviceNet, facilitating seamless integration into modern automation systems.

Product Specifications Table

Attribute	Specifications
Series	Sigma II
Manufacturer	Yaskawa
Power Rating	5.0 kW
Input Voltage Range	200-230V AC
Response Frequency	Up to 1 kHz
Protection Features	Overcurrent, overvoltage, and overheating protection
Compatible Encoder Types	Incremental and absolute encoders
Communication Protocols	MECHATROLINK-II, DeviceNet
Operating Temperature Range	0 °C to 55 °C
Capabilities	Auto-Tuning Capabilities
