Siemens 6GK7343-1EX20-0XE0

Siemens 6Gk7343-1Ex20-0Xe0

Siemens 6GK7343-1EX20-0XE0

The 6GK7343-1EX20-0XE0 is a communication processor from a renowned company Siemens. It is a global technology powerhouse focusing on the areas of electrification, automation, and digitalization. This processor has been designed for connecting SIMATIC S7-300 PLCs to Industrial Ethernet networks. It facilitates high-speed data exchange and ensures reliable communication between the automation system and other networked devices.

Technical Specifications:

The Siemens 6GK7343-1EX20-0XE0 communications processor carries a data transmission rate of 10 Mbps and 100 Mbps. It is powered by a dual voltage supply of +5 V DC and +24 V DC, both with a tolerance of ±5%. This flexibility in power options enhances its adaptability in many industrial settings.

The current consumption of the processor is approximately 200 mA and this value is almost equal to 0.2A. Additionally, the module consisted of a power loss of about 5.8 watts which helps in optimizing its energy consumption profile.

In terms of design, it features a compact module format specifically for the S7-300 series, with a double-width configuration. The dimensions of the module are 80 mm in width, 125 mm in height, and 120 mm in depth. This compact design allows for easy integration into existing systems without requiring significant space.

This processor weighs approximately 600 grams, and is lightweight yet durable, ensuring ease of handling and installation. This combination of all makes it an excellent choice for enhancing industrial network communications while maintaining robust performance.

Operational and Installation Parameters:

This communications processor 6GK7343-1EX20-0XE0 is intended for use with an S7-300 programmable logic controller. It connects to the backplane bus using the provided bus connector. For optimal operation, the CPU, communications processor, and interface module if available, should share the same power source.

The front panel of the processor has five LEDs that show its operational mode, along with two more LEDs that view communication rank. It operates reliably within a temperature range of 0 °C to +60 °C and functions effectively in environments with up to 95% relative humidity at 25 °C and at altitudes up to 2000 meters above sea level.

Safety Precautions:

Make sure to turn off the power before connecting S7-300 or C7-300 to the processor. Install the module in a way that keeps its top and bottom ventilation blocks clear for proper airflow. After setup, remember to reload the configuration data. Follow accurate voltage and current ratings as explained in the instructions guides.

Avoid exposing the module to extreme temperatures or humidity. Ensure the equipment is grounded properly to prevent electrical hazards. Use anti-static wristbands or mats to prevent damage to sensitive electronic components from static discharge. Regularly check connections for any signs of wear or damage to maintain safe operation.

Frequently Asked Questions:

What is the power loss of 6GK7343-1EX20-0XE0?

The maximum power loss for the communication processor is about 5.8 W which assists in optimizing its energy consumption level. This ensures efficient operation and reduced heat dissipation in various industrial applications.

What is the operating voltage range of the 6GK7343-1EX20-0XE0?

The processor has a dual voltage supply of +5 V DC and +24 V DC, both with a tolerance of ±5%. This versatile voltage range allows for reliable operation in different electrical environments and configurations.

Give the transmission rate for the Siemens processor 6GK7343-1EX20-0XE0?

The communication processor consisted of a transmission rate of up to 10 and 100 Megabits per second. This high-speed capability ensures rapid data transfer and efficient network performance in industrial automation settings.

Product Specifications Table

Attribute Specifications
Company Siemens
Series S7-300
Voltage range (V) 5 and 24 DC Weight (g) 600 Power loss (W) 5.8 Humidity up to 95% Ambient Temperature Range 0 to +60 degrees C Maximum consumed current (A) 0.2 Transfer rate (Mbit/s) 10 and 100

Siemens 6GK7343-1EX20-0XE0

Regular price
$1,878.00
Sale price
$1,878.00
We currently have 1 in stock.
Checkmark

In stock - Ships Today

Checkmark

Eligible for Next Day Delivery

Checkmark

Ships From Our North Carolina Warehouse

Eligible for Next Day Delivery All Parts Come with 24 Month Warranty New, Refurbished and Repairs Available


We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.


All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.


Payment options

We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.

Credit Terms

We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.
