Siemens 6SL3120-1TE28-5AA3
Siemens 6SL3120-1TE28-5AA3
A high-performance motor module from Siemens's S120 product series is the 6SL3120-1TE28-5AA3. This motor module guarantees effective control and driving of different motors and is designed for use in industrial applications. Motor operations in harsh settings may be accomplished with precision and reliability because to its superior features and sturdy build.
Technical Specifications:
With a DC 600V input and a 3AC 400V output, the 6SL3120-1TE28-5AA3 can run. A rated output current of 110.0 A and a base load current of 85A are its specifications. At 40% S6 duty, the current demand reaches 141.0 A, while the DC-link current is rated at 200 A for IH and 85.0 A for IN.
In order to regulate motors efficiently, the module runs at a rated pulse frequency of 4.00 kHz, which guarantees high-frequency switching. A variety of modes for controlling the output frequency are available, including servo control (0–650 Hz), vector control (0–300 Hz), and V/f control (0–600 Hz), providing flexible options for controlling the frequency.
The DC link capacitance of 1880 µF on the 6SL3120-1TE28-5AA3 is enough to maintain a stable DC link voltage even when subjected to transient situations. It may be deployed at elevations up to 3281 feet without derating and functions efficiently up to 40 degrees. To keep the module at the ideal working temperatures, the air cooling system needs a cooling air flow of 0.044 m³/s.
Physical Dimensions and Installation:
The Siemens 6SL3120-1TE28-5AA3 drive unit is designed to seamlessly fit into most industrial spaces, ensuring versatility and ease of use. It measures 7.87 inches (200 mm) in width, 14.96 inches (380 mm) in height, and 10.63 inches (270 mm) in depth. These compact dimensions allow it to be conveniently installed in various settings without requiring extensive space. Additionally, its net weight of 33.07 lbs (15 kg) facilitates handling and installation, minimizing the effort and resources needed for setup.
When it comes to electrical connections, the module is designed with practicality and safety in mind. The motor end version accepts a range of conductors from 14 to 2 AWG, which are secured using an M8 bolt. Moreover, the Protective Earth connection uses an M6 screw, providing a secure and reliable grounding method that is critical for safe operation in industrial environments.
The 6SL3120-1TE28-5AA3 also excels in cable management, accommodating both shielded and unshielded cables. It supports cable lengths up to 100 meters (328 feet) for standard installations and up to 150 meters (492 feet) for specific applications. The ability to handle such cable lengths is crucial for large-scale industrial operations where machinery may be spread over significant distances.
Compliance and Standards:
The Siemens 6SL3120-1TE28-5AA3 is reliable and safe for use in industrial settings because it meets multiple international standards. Protected from dust and unintentional contact with live parts to a substantial degree, this device has an IP20/UL rating.
The module's conformity with RoHS standards since July 2015 shows that it follows environmental regulations, guaranteeing that it does not contain any harmful compounds. For businesses concerned about their impact on the environment, this compliance makes it a viable option.
Frequently Asked Questions:
What size is the Siemens 6SL3120-1TE28-5AA3?
The Siemens 6SL3120-1TE28-5AA3 is 380.00 mm (14.96 in) tall, 270.00 mm (10.63 in) wide, and 200.00 mm (7.87 in) deep.
What is the Siemens 6SL3120-1TE28-5AA3's cooling method?
The Siemens 6SL3120-1TE28-5AA3 has internal air cooling. For optimal performance, the cooling air flow rate should be 0.044 m³/s.
Siemens 6SL3120-1TE28-5AA3 is equipped with what type of construction?
Siemens 6SL3120-1TE28-5AA3 is book-sized. This design fits easily in limited spaces with other modules.
Product Specifications Table:
| Attribute | Specification |
|---|---|
| Installation altitude | 1000 m (3281 ft) |
| Cooling method | Internal air cooling |
| Ambient temperature | 0 ... 40 °C (32 ... 104 °F) |
| Cooling air requirement | 0.044 m³/s |
| Max motor cable length (shielded) | 100 m (328 ft) |
| Max motor cable length (unshielded) | 150 m (492 ft) |
| PE connection | M6 screw |
| Base load current (IH) | 85.0 A |
| Rated output power based on IH | 37.0 kW |
| DC link capacitance | 1880 µF |
We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Payment options
We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.
Credit Terms
We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.
Description
Siemens 6SL3120-1TE28-5AA3
A high-performance motor module from Siemens's S120 product series is the 6SL3120-1TE28-5AA3. This motor module guarantees effective control and driving of different motors and is designed for use in industrial applications. Motor operations in harsh settings may be accomplished with precision and reliability because to its superior features and sturdy build.
Technical Specifications:
With a DC 600V input and a 3AC 400V output, the 6SL3120-1TE28-5AA3 can run. A rated output current of 110.0 A and a base load current of 85A are its specifications. At 40% S6 duty, the current demand reaches 141.0 A, while the DC-link current is rated at 200 A for IH and 85.0 A for IN.
In order to regulate motors efficiently, the module runs at a rated pulse frequency of 4.00 kHz, which guarantees high-frequency switching. A variety of modes for controlling the output frequency are available, including servo control (0–650 Hz), vector control (0–300 Hz), and V/f control (0–600 Hz), providing flexible options for controlling the frequency.
The DC link capacitance of 1880 µF on the 6SL3120-1TE28-5AA3 is enough to maintain a stable DC link voltage even when subjected to transient situations. It may be deployed at elevations up to 3281 feet without derating and functions efficiently up to 40 degrees. To keep the module at the ideal working temperatures, the air cooling system needs a cooling air flow of 0.044 m³/s.
Physical Dimensions and Installation:
The Siemens 6SL3120-1TE28-5AA3 drive unit is designed to seamlessly fit into most industrial spaces, ensuring versatility and ease of use. It measures 7.87 inches (200 mm) in width, 14.96 inches (380 mm) in height, and 10.63 inches (270 mm) in depth. These compact dimensions allow it to be conveniently installed in various settings without requiring extensive space. Additionally, its net weight of 33.07 lbs (15 kg) facilitates handling and installation, minimizing the effort and resources needed for setup.
When it comes to electrical connections, the module is designed with practicality and safety in mind. The motor end version accepts a range of conductors from 14 to 2 AWG, which are secured using an M8 bolt. Moreover, the Protective Earth connection uses an M6 screw, providing a secure and reliable grounding method that is critical for safe operation in industrial environments.
The 6SL3120-1TE28-5AA3 also excels in cable management, accommodating both shielded and unshielded cables. It supports cable lengths up to 100 meters (328 feet) for standard installations and up to 150 meters (492 feet) for specific applications. The ability to handle such cable lengths is crucial for large-scale industrial operations where machinery may be spread over significant distances.
Compliance and Standards:
The Siemens 6SL3120-1TE28-5AA3 is reliable and safe for use in industrial settings because it meets multiple international standards. Protected from dust and unintentional contact with live parts to a substantial degree, this device has an IP20/UL rating.
The module's conformity with RoHS standards since July 2015 shows that it follows environmental regulations, guaranteeing that it does not contain any harmful compounds. For businesses concerned about their impact on the environment, this compliance makes it a viable option.
Frequently Asked Questions:
What size is the Siemens 6SL3120-1TE28-5AA3?
The Siemens 6SL3120-1TE28-5AA3 is 380.00 mm (14.96 in) tall, 270.00 mm (10.63 in) wide, and 200.00 mm (7.87 in) deep.
What is the Siemens 6SL3120-1TE28-5AA3's cooling method?
The Siemens 6SL3120-1TE28-5AA3 has internal air cooling. For optimal performance, the cooling air flow rate should be 0.044 m³/s.
Siemens 6SL3120-1TE28-5AA3 is equipped with what type of construction?
Siemens 6SL3120-1TE28-5AA3 is book-sized. This design fits easily in limited spaces with other modules.
Product Specifications Table:
| Attribute | Specification |
|---|---|
| Installation altitude | 1000 m (3281 ft) |
| Cooling method | Internal air cooling |
| Ambient temperature | 0 ... 40 °C (32 ... 104 °F) |
| Cooling air requirement | 0.044 m³/s |
| Max motor cable length (shielded) | 100 m (328 ft) |
| Max motor cable length (unshielded) | 150 m (492 ft) |
| PE connection | M6 screw |
| Base load current (IH) | 85.0 A |
| Rated output power based on IH | 37.0 kW |
| DC link capacitance | 1880 µF |
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
TECHNICAL SPECIFICATIONS
6SL3120-1TE28-5AA3 Single Motor Module
Overview
The 6SL3120-1TE28-5AA3 is a Single Motor Module from Siemens' SINAMICS S120 series. This module is designed for use with DC 600V input and has an output of 3AC 400V with 85A. The frame size is booksize and features internal air cooling for optimal performance.Features and Benefits
The 6SL3120-1TE28-5AA3 boasts many notable features that make it a top choice for various applications. Its optimized pulse sample allows for precise motor movement control, making it ideal for smooth and accurate motor control applications. This could include industries such as robotics or automation. The module's internal air-cooling system helps keep the motor running at optimal temperatures, increasing its lifespan and reducing maintenance. Its book-size frame makes integrating various systems and applications easy. In addition to its optimized pulse sample, the 6SL3120-1TE28-5AA3 also supports the extended safety integrated functions of the SINAMICS S120 series. These functions include safety shutdowns, emergency stop, and other measures to ensure the safe operation of the motor module. This is important for applications where safety is a top priority, such as manufacturing. Another standout feature of the 6SL3120-1TE28-5AA3 is its inclusion of a Drive-CLIQ cable. This cable allows for accessible communication and data exchange with other devices in the SINAMICS system, simplifying integration into larger systems. This is particularly useful for applications where the motor module is just one part of a more extensive system, such as in a factory setting.Specifications
- Input: DC 600V
- Output: 3AC 400V, 85A
- Frame size: booksize
- Internal air cooling
- Optimized pulse sample
- Support of extended safety integrated functions
- Drive-CLIQ cable included
Shipping
The 6SL3120-1TE28-5AA3 has dimensions of 16.0" x 14.0" x 22.0" and a weight of 35 lbs. Its tariff code is 8504907500, and it is made in Germany.Compatibility
This Single Motor Module is compatible with Siemens' SINAMICS and SINAMICS S120 systems. It can be easily integrated into these systems thanks to its support of the extended safety integrated functions and the inclusion of the Drive-CLIQ cable.
