Siemens 6SL3120-2TE21-0AD0

Siemens 6Sl3120-2Te21-0Ad0

Siemens 6SL3120-2TE21-0AD0

A high-performance drive module, the 6SL3120-2TE21-0AD0 was built by Siemens for industrial applications requiring precise motor control. Because of its compact design and cutting-edge features, which ensure reliable operation, it is an ideal choice for boosting productivity and efficiency in a broad variety of demanding applications.

Technical Specifications:

The dimensions of the Siemens 6SL3120-2TE21-0AD0 are 270.00 mm in height, 50.00 mm in width, and 380.00 mm in depth. It has an IP20 rating and is UL open type protected, and it weighs 4.7 kg net.

A 0.009 m³/s airflow is used to effectively manage cooling by the internal air conditioning system. You may mount the drive at 3281 ft without derating it, and it works best between 0 and 40 °C. You have a lot of leeway in deciding where to put the motor because the maximum distance for shielded cables is 50 meters (164 feet) and the maximum for unshielded wires is 75 meters (246 feet).

Two to six millimeters squared (16 to ten AWG) of wires can be securely fastened to the drive via its PE connector using an M5 screw. Ensuring quality and safety, CE and cULus certifications are in place. For more peaceful functioning, the sound pressure level is maintained at 60.0 dB at 1 meter.

Electrical Specifications:

When it comes to electrical standards, Siemens 6SL3120-2TE21-0AD0 is top-notch. It can produce two different currents, 12.0 A and 7.7 A, with a maximum output current of 22.0 A. The input voltage is 4.1 kW, and the rated base load current is 9.0 A multiplied by 2. With a steady DC 24 V supply, this drive can withstand changes ranging from -15% to +20%.

For 40% S6 duty cycles, the drive can manage 2 x 27.0 A IS6 currents. Depending on IH, the DC link current ID can range from 20 A to 100 A Imax. The pulse frequency is 4.00 kHz, and the DC link voltage can range from 510 to 720 V. A wide range of applications can be efficiently served by this drive, thanks to its 2 × 4.8 kW IN type rating.

The DC link capacitance of the Siemens 6SL3120-2TE21-0AD0 is 220 µF. Servo, vector, and V/f control are accomplished using its three output frequencies: 650 Hz, 300 Hz, and 600 Hz. These frequencies provide a range of customizable control choices to meet unique needs. Power loss ranges from an average of 0.15 kW to a maximum of 0.19 kW.

Overvoltage, undervoltage, overcurrent, and heat protection are all built-in safety measures. An indication of the drive's care for the environment is its RoHS certification. Dependability is ensured in a variety of situations by the drive, which permits installation heights of up to 1000 meters without derating.

Additional Specifications:

Servo, vector, and V/f control types are all compatible with this drive, and it comes with an inbuilt LED display for a simple way to check status. Communication interfaces like PROFIBUS DP and PROFINET allow for integration with industrial networks. Ensuring strict adherence to RoHS requirements, the drive offers robust environmental protection.

Frequently Asked Questions:

What is the level of protection provided for the Siemens 6SL3120-2TE21-0AD0?

Siemens 6SL3120-2TE21-0AD0 is IP20 / UL open-type protected. This rating qualifies it for industrial settings.

What is the maximum allowable length of the motor cable for the Siemens 6SL3120-2TE21-0AD0?

Siemens 6SL3120-2TE21-0AD0 motor cables can be 50 meters shielded and 75 meters unshielded. This allows installation flexibility.

What is the power dissipation of the Siemens 6SL3120-2TE21-0AD0?

The power loss of the Siemens 6SL3120-2TE21-0AD0 is 0.15 kW on average and 0.19 kW at its peak. Energy efficiency is assured with this drive.

Product Specifications Table:

Attributes Specification
Height 270.00 mm (10.63 in)
Width 50.00 mm (1.97 in)
Depth 380.00 mm (14.96 in)
Net Weight 4.7 kg (10.36 lb)
Degree of Protection IP20 / UL open type
Type of Construction Booksize
Sound Pressure Level (1m) 60.0 dB
Cooling Air Requirement 0.009 m³/s
Ambient Temperature During Operation 0 ... 40 °C (32 ... 104 °F)
Installation Altitude (Without Derating) 1000 m (3281 ft)
