Siemens 6SL3210-1PE28-8UL0
Siemens 6SL3210-1PE28-8UL0
The Siemens 6SL3210-1PE28-8UL0 is a Power Module designed for industrial applications. Siemens is a global leader in industrial automation, known for its innovative and reliable solutions. It offers reliable performance with high efficiency and compliance with various standards. This module supports three-phase AC input and output, making it suitable for diverse environments.
Output Specifications:
The output specifications of the Power Module 6SL3210-1PE28-8UL0 include a rated current of 90.00 A (LO) and 75.00 A (HO). It has a maximum output current that reaches 150.00 A. The rated power is 45.00 kW (LO) and 37.00 kW (HO). The module operates at a rated voltage of 400V IEC and 480V NEC. The 4 kHz pulse frequency of power module ensures stable performance in demanding conditions.
Input and Mechanical Specifications:
For input, the Power Module supports three-phase AC with a line voltage range of 380 to 480 V ±10%. The rated current is 86.00 A (LO) and 78.00 A (HO). These features ensure consistent power delivery and adaptability to varying power sources, enhancing its versatility in industrial settings.
The mechanical dimensions of the Siemens 6SL3210-1PE28-8UL0 are 275 mm in width, 551 mm in height, and 237 mm in depth. The net weight of the power module is 26.00 kg. The frame size is FSE, suitable for compact installations in restricted spaces.
This module also meets UL, cUL, CE, C-Tick (RCM), and SEMI F47 standards, indicating its compliance with international safety and performance regulations. It bears the CE marking under the Low-voltage directive 2006/95/EC, ensuring adherence to essential health and safety requirements. These certifications ensure that the module meets rigorous quality and safety standards, making it reliable for critical applications.
General Technical Specifications:
General technical specifications highlight its power loss of 1.19 kW and a power factor of ? 0.95. The module's efficiency is rated at 0.98, and the offset factor cos ? is 0.99. These features contribute to its high energy efficiency, reducing operational costs. The high efficiency rating ensures that the module operates with minimal energy waste, maximizing performance while conserving power.
The Siemens Power Module operates efficiently within various ambient conditions, including an installation altitude of up to 1,000 meters. This ensures optimal thermal management during operation, preventing overheating. The internal cooling system is designed to maintain the module's performance under continuous operation, even in challenging environments.
Temperature specifications for the module include an operational range of -20 to 40 °C (LO) and -20 to 50 °C (HO). For transport, it can withstand temperatures from -40 to 70 °C. These temperature ranges ensure the module's reliability in diverse environmental conditions, from cold storage to hot industrial environments. Its robust design makes it suitable for various applications, ensuring long-term durability and consistent performance.
Frequently Asked Questions:
What are the output specifications of the Siemens 6SL3210-1PE28-8UL0 Power Module?
The Siemens 6SL3210-1PE28-8UL0 Power Module has a rated current of 90.00 A (LO) and 75.00 A (HO). It delivers a maximum output current of 150.00 A. The rated power is 45.00 kW (LO) and 37.00 kW (HO), operating at a rated voltage of 400V IEC and 480V NEC.
What are the mechanical dimensions and weight of the Siemens 6SL3210-1PE28-8UL0 Power Module?
The Siemens 6SL3210-1PE28-8UL0 Power Module measures 275 mm in width, 551 mm in height, and 237 mm in depth. It has a net weight of 26.00 kg. The frame size is FSE, which makes it suitable for compact installations in restricted spaces.
What is the power efficiency of the Siemens 6SL3210-1PE28-8UL0 Power Module?
The Siemens 6SL3210-1PE28-8UL0 Power Module has a high efficiency rating of 0.98. It contributes to its energy-efficient performance.
Product Specifications Table
| Attribute | Specifications |
|---|---|
| Number of Output Phases | 3 AC |
| Max. Output Current | 150.00 A |
| Rated Voltage | 400V IEC / 480V NEC |
| Pulse Frequency | 4 kHz |
| Input Line Voltage | 380 ... 480 V ±10 % |
| Input Line Frequency | 47 ... 63 Hz |
| Dimensions (W x H x D) | 275 mm x 551 mm x 237 mm |
| Net Weight | 26.00 kg (57.32 lb) |
| Standards Compliance | UL, cUL, CE, C-Tick (RCM), SEMI F47 |
| Operating Temperature Range (Low) | -20 ... 40 °C (-4 ... 104 °F) |
