Description

Siemens 6SL3210-1PE31-1UL0

The Siemens 6SL3210-1PE31-1UL0 Power Module is designed to meet various international standards. It complies with SEMI F47, UL, cUL, CE, and C-Tick (RCM) standards. It also has the Low-voltage directive 2006/95/EC CE certification on it. Siemens is renowned for its innovative solutions in electrification, automation, and digitalization.

Connections Specifications:

The power module features screw-type terminals for the line side and motor end connections. The model can accommodate conductor cross-sections between 25.00 and 70.00 mm², or AWG 4 and AWG -1.

For the DC link, which is used for the braking resistor, it also employs screw-type terminals and supports conductor cross-sections from 10.00 to 35.00 mm², equivalent to AWG 8 to AWG 2. Motor cables can have a maximum length of 200 meters when shielded and 300 meters when they are unshielded. The PE connection is made using screw-type terminals.

The Siemens 6SL3210-1PE31-1UL0 Power Module operates with three AC phases for both input and output. It operates within the input line voltage range of 380 to 480 V ±10% at a line frequency of 47 to 63 Hz. For high and low operation, the rated current is 94.00 A and 104.00 A, respectively.

The rated voltage for output is 400V IEC or 480V NEC. The rated power for low operation is 55.00 kW or 75.00 hp, and for high operation, it is 45.00 kW or 60.00 hp. The output current can reach a maximum of 180.00 A. The power module has a 4 kHz pulse frequency.

Ambient Conditions:

The Siemens 6SL3210-1PE31-1UL0 Power Module operates under specific ambient conditions. It can handle relative humidity up to 95% without condensation. The module is air-cooled inside and can be installed at elevations as high as 1,000 meters. For low operation, the ambient temperature is between -20 and 40 °C, and for high operation, it is between -20 and 50 °C.

The product code, 6SL3210-1PE31-1UL0, and the product name, Power Module, should be noted when referring to this Siemens device. This module is built to support high-performance needs in various industrial applications. It is designed with both durability and efficiency in mind, making it a valuable component in power management systems.

Additional Specifications:

The Siemens 6SL3210-1PE31-1UL0 Power Module complies with several international standards, ensuring reliable and safe performance.

The power module's high efficiency, with an efficiency rating of 0.98, ensures that energy is utilized effectively, reducing waste and improving overall performance. Its reliable performance is further enhanced by the offset factor of 0.99, which makes it an excellent option for a range of industrial applications.

h2>Frequently Asked Questions:

What are the compliance standards of the Siemens 6SL3210-1PE31-1UL0 Power Module?

The Siemens 6SL3210-1PE31-1UL0 Power Module complies with UL, cUL, CE, C-Tick (RCM), and SEMI F47 standards. In addition, the Low-voltage directive 2006/95/EC CE certification verifies that it satisfies a number of global safety and performance requirements.

What are the input and output specifications of this power module?

The module operates with three AC phases for both input and output. A tolerance of ±10% is present in the input line voltage, which ranges from 380 to 480 V at 47 to 63 Hz. With a rated power of 55.00 kW for low operation and 45.00 kW for high operation, the output has a 400V IEC rated voltage.

What is the efficiency and power factor of the Siemens 6SL3210-1PE31-1UL0 Power Module?

The Siemens 6SL3210-1PE31-1UL0 Power Module has an efficiency rating of 0.98, ensuring optimal energy utilization. With a 0.95 power factor and 0.99 offset factor, it is a reliable solution that works well in many industrial applications.

Product Specifications Table

Attribute Specifications
Manufacturer Siemens
Product Type Power Supply Module
Power Factor ? 0.95
Efficiency ? 0.98
Motor Cable Length (Shielded) 200 m (656.17 ft)
Motor Cable Length (Unshielded) 300 m (984.25 ft)
Operating Temperature (LO) -20 ... 40 °C (-4 ... 104 °F)
Rated Voltage 400V IEC, 480V NEC
Rated Power (LO) 55.00 kW / 75.00 hp
Rated Power (HO) 45.00 kW / 60.00 hp
