Siemens 6SL3210-1KE21-3AF1
An extremely efficient frequency drive is the 6SL3210-1KE21-3AF1 from Siemens. Robust performance, energy economy, and numerous connecting choices are designed into this inverter, making it ideal for versatile applications. With its dependable motor control and high-tech features that boost operating efficiency and safety, it's perfect for use in industrial settings.
Technical Specifications:
This Siemens 6SL3210-1KE21-3AF1 can bear voltage fluctuations of up to ±10% and operates from 380 to 480 volts. It can adapt to varied power supplies because its input frequency is 47 to 63 Hz. According to the inverter's rated current, low overload current is 16.50 A and high is 12.80 A. This difference ensures the inverter can efficiently handle load needs.
Inverter output frequency ranges for V/f and vector control are 0240 and 0550 Hz, respectively. It performs well in many applications with a maximum output current of 17.60 A. Its efficiency rating of 0.97 and power factor of 0.700.85 indicate its efficiency. Additionally, its 63 dB sound pressure level makes it quiet in industrial settings.
The 6SL3210-1KE21-3AF1 is strong and compact. It fits into standard control cabinets at 196 mm tall, 100 mm wide, and 203 mm deep. The 3.0 kilogram inverter is lightweight and sturdy. Its IP20 certification makes it appropriate for controlled environments. The integrated air conditioning system's internal fan ensures consistent performance and thermal management.
Six digital inputs, two digital outputs, one analog input, and one analog output allow the inverter to link to many sensors and control systems. The integrated PROFINET-PN fieldbus simplifies system integration and data interchange with other automation components.
Safety and Compliance:
Siemens 6SL3210-1KE21-3AF1 incorporates a Safe Torque Off feature to turn off the motor in an emergency without mistakenly starting it. It meets RoHS and REACH standards, making this inverter safe and eco-friendly. It also follows the WEEE directive, which encourages green recycling and disposal.
This Siemens 6SL3210-1KE21-3AF1 can withstand several environmental conditions. Optimal operation temperature is -10 to 40°C, and storage is -40 to 70°C. Installation altitude can reach 1000 meters without derating, making it suitable for many locations. The inverter can operate in 95% relative humidity without ice or condensation.
Applications and Integration:
Siemens 6SL3210-1KE21-3AF1 is well-suited for a wide range of industrial uses due to its adaptability. Conveyor systems, pumps, fans, and compressors frequently employ it for applications requiring exact motor control. No matter how taxing the application, the inverter will maintain its steady performance because to its high overload capability, which lets it tolerate unexpected variations in load. Improve the inverter's compatibility with sensitive equipment by minimizing electromagnetic interference with the included Class A filter.
Frequently Asked Questions:
What is the maximum current output and efficiency of the Siemens 6SL3210-1KE21-3AF1?
The Siemens 6SL3210-1KE21-3AF1 has a maximum output current of 17.60 A and an efficiency rating of 0.97. These specifications ensure robust performance and high operational efficiency in various industrial applications.
Can the Siemens 6SL3210-1KE21-3AF1 operate at high altitudes and what is its sound pressure level?
Yes, the Siemens 6SL3210-1KE21-3AF1 can operate at altitudes up to 1000 meters without derating. It has a sound pressure level of 63 dB, which ensures relatively quiet operation in industrial environments.
What type of protection does the Siemens 6SL3210-1KE21-3AF1 offer and what is its rated current for high overload?
The 6SL3210-1KE21-3AF1 from Siemens has a rated current of 12.80 A(HO) and an IP20 protection grade. All of these safeguards make sure the inverter can manage heavy loads with ease.
Product Specifications Table:
| Attributes |
Specification |
| Rated Current (IN) |
13.00 A |
| Max. Output Current |
17.60 A |
| Pulse Frequency |
4 kHz |
| Output Frequency (Vector Control) |
0 ... 240 Hz |
| Rated Power (LO) |
5.50 kW / 7.50 hp |
| Rated Power (HO) |
4.00 kW / 5.00 hp |
| Cooling Requirement |
0.009 m³/s (0.318 ft³/s) |
| Operating Temperature |
-10 ... 40 °C (14 ... 104 °F) |
| Communication Interfaces |
PROFINET, EtherNet/IP |
| Degree of Protection |
IP20 / UL open type |
