Siemens 6SN1118-0DK23-0AA1

Siemens 6Sn1118-0Dk23-0Aa1

Siemens 6SN1118-0DK23-0AA1

The 6SN1118-0DK23-0AA1 from Siemens is a digital control loop block from the SIMODRIVE 611 series that is known for its excellent performance. This component is crucial for the efficient and accurate management of different types of motors and is designed for use in industrial applications requiring precise control. The automotive and aerospace sectors, which are known for their harsh environments, are ideal for this product due to its advanced features and compatibility.

Technical Specifications:

With its high-performance engineering, the Siemens 6SN1118-0DK23-0AA1 enables two-axis control. Several motor series are compatible with it, such as 1FT6, 1FK, 1FN1, 1FN3, and 1FE1. The EnDat interface also allows it to link to absolute encoders, which further guarantees accurate feedback for fine-tuned motor control. For improved control performance, the module makes use of sinusoidal voltage signals, allowing for precise and trouble-free motor operation.

Software versions of NC that are compatible with the product must be installed starting from 06.04.09. This includes NCU version 6.4.9 and drive version 6.3.11. This makes it easy to incorporate the unit into contemporary control systems. It is possible to use the module as a single-axis module if needed, adding to its versatility and adaptability to meet the needs of different applications.

With a net weight of about 0.53 kg, the device is physically tiny and easy to work with, either installing or maintaining it. Compact in stature, it is well-suited for use as an FD or MSD main spindle drive thanks to its strong performance. For complicated industrial setups requiring various forms of motor control, this adaptability is vital.

Features and Compatibility:

SIMODRIVE 611 series scalable and modular drive 6SN1118-0DK23-0AA1 from Siemens. This allows it to be readily linked to larger control systems, improving operating efficiency. The module works with 1PH, 1 PM, and 1FM6 motors for industrial use.

This control loop block is famous for its ability to link to direct measuring devices. These allow fine control using sin/cos 1 signals. With the EnDat and SSI connections, it may evaluate two direct measuring systems simultaneously, increasing its versatility. This dual compatibility excels in precision and dependability.

Application and Integration:

The Siemens 6SN1118-0DK23-0AA1 is reliable and excellent for automotive, aerospace, power generation, and electronics applications. It's ideal for complex automation systems due to its comprehensive motor and encoder compatibility. The module's capacity to regulate feed drive and primary spindle drive operations makes it versatile for many industrial needs.

During initialization or reset, the SINUMERIK 840 D's control loop block and drive software to simplify setup. This automated software delivery keeps the module running the latest and most suitable software, reducing maintenance and downtime. The modular nature of the control system enables easy updates and replacement inside the SIMODRIVE system, extending its lifespan.

Frequently Asked Questions:

Does the Siemens 6SN1118-0DK23-0AA1 have RoHs compliance, and what is its net weight?

The 6SN1118-0DK23-0AA1 has lead levels of more than 0.1% by weight, making it non-RoHS compliant. The device weighs in at a little 0.53 kg net.

What is the application environment for the Siemens 6SN1118-0DK23-0AA1, and which software versions are compatible with it?

The module is utilized in the power generation, aerospace, and automotive sectors, and it is compatible with NC software versions starting from 06.04.09.

What voltage signals does the Siemens 6SN1118-0DK23-0AA1 employ, and how is it operated as a single-axis module?

If necessary, the 6SN1118-0DK23-0AA1 can be set to operate as a single-axis module and uses sinusoidal voltage signals for control performance.

Product Specification Table:

Attributes Specification
Manufacturer Siemens
Series SIMODRIVE 611
Control Type 2-axis High Performance
Motor Compatibility 1FT6, 1FK, 1FN1, 1FN3, 1FE1, 1PH, 1PM, 1FM6
Encoder Interface EnDat, SIN/COS 1 Vpp
Weight 0.53 kg
RoHS Compliance Not RoHS compliant
Software Requirements NCU ? 6.4.9, Drive ? 6.3.11
Applications Automotive, Aerospace, Power Generation
Product Status Discontinued
