Toshiba VFAS3-4370PC
Toshiba VFAS3-4370PC
A high-performance ASD from Toshiba's AS3 family is the VFAS3-4370PC. For use in manufacturing, it regulates and enhances the efficiency of electric motors. A favorite in harsh settings, this type is renowned for its dependability, high-tech motor control capabilities, and sturdy construction.
Technical Specifications:
The Toshiba VFAS3-4370PC can handle three-phase input systems because it runs on 460 volts. It can efficiently operate motors for large-scale industrial applications thanks to its 60 horsepower power rating. With a 150% overload capacity for heavy-duty applications and a 120% overload capacity for normal-duty applications, the drive allows dual ratings through parameter modifications.
Eight programmable digital inputs let you tailor this model to your operations. For better control and monitoring, it incorporates two Form-A dry contact relays and one Form-C relay with programmable digital outputs. The VFAS3-4370PC has three programmable analog inputs that receive signals from 0-10 VDC to +10 VDC for accurate adjustments and sensor feedback.
The integrated RS485 (two-wire and four-wire) and dual-port Ethernet IP interfaces simplify integration and networking. These capabilities guarantee that other industrial control systems can be easily connected to and data exchanged with.
To make management and troubleshooting easier, the embedded web server allows for remote setting and monitoring. In addition, the drive has a built-in clock that allows for precise trip tracking and calendar features that help with better maintenance management.
Applications:
The Toshiba VFAS3-4370PC is ideal for industrial applications that require accurate motor control and reliability. Standard applications include compressor, fan, conveyor, and pump management. Its durability makes it ideal for manufacturing, water treatment, HVAC, and material handling applications.
In manufacturing, the drive is essential for machine and assembly line efficiency. It optimizes pumps and aeration systems to improve water treatment efficiency and reliability. The VFAS3-4370PC controls airflow and temperature to keep large buildings pleasant and energy efficient.
Installation Guidelines:
Correct installation is vital for the Toshiba VFAS3-4370PC to perform well and endure long. The drive can overheat and get contaminated if not kept clean, dry, and aired. Install the drive upright on a firm, vibration-free surface to avoid mechanical stress.
Follow the manual's wire diameter and torque guidelines while wiring the drive. For electrical safety, ensure enough insulation and tight connections. Grounding the drive reduces electrical noise and improves safety.
You must first determine your application's parameters before programming the drive. Ethernet IP or RS485 connections make integration with current control systems easy. Remote access and configuration via the included web server simplifies monitoring and troubleshooting.
Check the drive for dust and dirt, tighten all connections, and update firmware as needed as part of routine maintenance. Use trip monitoring and real-time clocks to plan preventative maintenance and avoid problems.
Frequently Asked Questions:
The VFAS3-4370PC has how many digital outputs, and what kinds of communication interfaces are it capable of?
Built within the drive are two Ethernet IP and RS485 ports for connecting devices. For versatile control system integration, it comes with three programmable digital outputs as well.
The VFAS3-4370PC has an embedded web server and a real-time clock; what do these components do?
The integrated web server improves manageability by allowing remote settings and monitoring. In order to effectively schedule maintenance, the real-time clock offers calendar functionalities and thorough trip monitoring.
To what extent does the VFAS3-4370PC's QR code display and dual rating feature enhance its performance?
Quickly get parameter information and troubleshooting advice using the QR code display. Parameter adjustments are made possible by the dual rating capability to accommodate both normal-duty and heavy-duty applications.
Product Specification Table:
| Attribute | Specification |
|---|---|
| Horsepower | 60 HP |
| Input Voltage | 460 V, Three-Phase |
| Output Current | 88 A |
| Heavy Duty Overload | 150% for 60 seconds |
| Normal Duty Overload | 120% for 60 seconds |
| Digital Inputs | Eight Programmable |
| Digital Outputs | Three Programmable |
| Analog Inputs | Three Programmable |
| Communication | Ethernet IP, RS485 |
| Safety Compliance | IEC 61800-5-2, SIL3 |
