Toshiba VFS15-4110PL-W1
Toshiba VFS15-4110PL-W1
Among the VF-S15 family of variable frequency drives, the high-performance VFS15-4110PL-W1 from Toshiba stands out. This high-tech industrial item has several potential uses due to its ability to control motors precisely. Efficiency and operational excellence are guaranteed under challenging conditions with the VFS15-4110PL-W1's reliable performance and comprehensive capabilities.
Technical Specifications:
With a strong power rating, the Toshiba VFS15-4110PL-W1 can handle applications requiring a constant torque of 11 kW (15 HP) and a variable torque of 15 kW (20 HP). It works well with three-phase AC input voltages between 380 and 500V. This variable frequency drive is compatible with a wide range of industrial motors because it can produce up to 500V AC voltages.
The drive's 36.6 A input current makes it capable of handling heavy electrical loads. With constant torque, the output current is 27.7 A, whereas with variable torque, it rises to 31 A. It has a wide frequency range, from 0.5 to 60 Hz by default, and can operate from 0.1 to 500 Hz. A wide range of operational needs can be met by extending the maximum frequency capability from 30 to 500 Hz.
The VFS15-4110PL-W1's sophisticated sensor less vector control improves motor performance and energy economy. It can handle 110% of the rated current when operating continuously and 150% for one minute, which is quite an excellent overload capability. Furthermore, the functioning is smooth and interference-free thanks to the built-in high-attenuation EMC filter.
Environmental and Physical Specifications:
This drive is designed to endure harsh environments and can continue to function well in temperatures as high as 50°C without experiencing any degradation. Further temperature increases can be achieved via de-rating. Because of its small size may be easily installed in tight quarters, making the most efficient use of available space in commercial and institutional settings.
An integrated control panel further streamlines the VFS15-4110PL-W1's user interface and settings. Its support for mounting on DIN rails makes installation in control cabinets or panels easy. A 24 VDC source can power the control portion, allowing more flexibility during installation and programming, particularly during the first setup.
Enhanced Control and Flexibility:
Built with an innovative vector-control algorithm, the VFS15-4110PL-W1 from Toshiba provides exceptional control and a wide range of features. This guarantees accurate speed management with a sensor-free precision of 0.1%. The drive can accommodate a wider variety of motor types because it is compatible with permanent magnet (PM) motors.
The drive's enhanced PID control allows for the exact control of intricate processes. Its constant operation under varied load situations and rigorous level control suits these applications. Energy reductions and operating cost optimization are both helped by user-selectable V/Hz patterns.
Frequently Asked Questions:
How vast is the frequency range that the Toshiba VFS15-4110PL-W1 can handle?
The default frequency range for the Toshiba VFS15-4110PL-W1 is 0.5 to 60 Hz. However, it can work within a range of 0.1 to 500 Hz. Controlling the motor's speed is a breeze with such a wide range.
How is the Toshiba VFS15-4110PL-W1 controlled?
The Toshiba VFS15-4110PL-W1 employs superior sensor less vector control. This approach offers accurate control without requiring a physical sensor, which enhances motor performance and energy economy.
Will the Toshiba VFS15-4110PL-W1 be able to handle extreme environments?
Without derating, the Toshiba VFS15-4110PL-W1 can function optimally in environments as hot as 50°C. Even in extreme environments, this sturdy construction will provide dependable operation.
Product Specifications Table:
| Attribute | Specification |
|---|---|
| Power Rating (Constant Torque) | 11 kW (15 HP) |
| Power Rating (Variable Torque) | 15 kW (20 HP) |
| Input Voltage Range | 380-500V AC, Three-phase |
| Output Voltage | Up to 500V AC |
| Input Current | 36.6 A |
| Output Current (Constant Torque) | 27.7 A |
| Output Current (Variable Torque) | 31 A |
| Frequency Range | 0.1 to 500 Hz (default 0.5 to 60 Hz, max 30 to 500 Hz) |
| Control Method | Sensorless Vector Control |
| Overload Capacity | 150% of rated current for 1 minute, 110% continuous |
We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.
All products (new, refurbished, and repairs) are covered under the Manufacturer's Warranty.
Payment options
We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.
Credit Terms
We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.
