Toshiba VFS15-4150PL-W1
Toshiba VFS15-4150PL-W1
An industrial drive from Toshiba's VFS15 family, the VFS15-4150PL-W1 offers exceptional performance. With its ability to regulate the rotational velocities of three-phase induction motors, it finds widespread use in manufacturing. This drive's sophisticated design and sturdy build guarantee better process control, more energy savings, and smooth motor running.
Technical Specifications:
For demanding tasks, go no further than the VFS15-4150PL-W1, which can handle motor powers up to 15 kW. It can handle a rated output current of 33.0 A and runs from 380V to 500V. The drive's robust 25.1 kVA capacity guarantees dependable operation, even in the most taxing environments.
An impressive aspect of this model is its ability to withstand transitory overloads, with ratings of 150% for 60 seconds and 200% for 0.5 seconds alike. With a 3-phase voltage range of 380V to 500V and a frequency of 50/60Hz, the power supply is stable under different power situations and allows voltage swings between 323V and 550V.
To ensure it complies with industrial requirements, the drive features an integrated EMC filter that reduces electromagnetic interference. It protects the internal components from dust and accidental touch and offers good thermal management with its forced air-cooled design and IP20 protection grade. It is small, lightweight, and easy to install, with dimensions of (180 x 310 x 190 )mm and a weight of 6.5 kg.
Dynamic braking capabilities are also included in the VFS15-4150PL-W1, which can be used with optional brake resistors like the PBR7-008W030. It allows for precise motor control using a sinusoidal PWM approach and supporting V/F control. To meet the needs of various industrial operations, the frequency setting ranges from 0.01 Hz up to 500 Hz.
Advanced Features:
To boost performance, this Toshiba drive offers cutting-edge technologies. Drives have various safety measures to ensure reliable and safe operation, including overcurrent, overvoltage, and undervoltage protection. Users can pick a parameter-adjustable carrier frequency control mode to improve performance and reduce motor noise.
Another impressive attribute is its adaptability. VFS15-4150PL-W1 works best when stored between -25 and +70°C and in an ambient temperature range of -10 to +60°C. This device is appropriate for many industrial applications because it resists non-condensing relative humidity from 5% to 95%. Current reduction is needed above 1000 meters. However, it's built for 3000 meters.
Installation and Usage:
The VFS15-4150PL-W1's small size and clear installation instructions make it easy to set up. Proper heat dissipation requires mounting the drive on a metal plate. Remove the protective label and lower the output current when operating in areas with temperatures exceeding 40°C; proper ventilation is paramount.
Applications that require exact speed adjustments can't do without the drive's frequency setting capabilities and control mechanism, allowing for fine-tuned motor control. Enhanced operating safety is achieved with the built-in dynamic braking technology, which enables rapid motor stops.
Frequently Asked Questions:
How many protection features does the Toshiba VFS15-4150PL-W1 offer?
Overvoltage, undervoltage, and overcurrent protections are all included in the Toshiba VFS15-4150PL-W1. These features guarantee that the drive can operate reliably and safely in various industrial settings.
Under what circumstances can the Toshiba VFS15-4150PL-W1 manage an overload?
When faced with an overload, the Toshiba VFS15-4150PL-W1 can withstand a current rating of 150% for 60 seconds and 200% for 0.5 seconds, giving it a strong defense against temporary overloads.
Does the Toshiba VFS15-4150PL-W1 include an integrated filter?
Toshiba VFS15-4150PL-W1 has an EMC filter. This function optimizes system performance and ensures industrial compliance by decreasing electromagnetic interference.
Product Specifications Table:
| Attribute | Specification |
|---|---|
| Motor Power Capacity | 15 kW |
| Voltage Range | 380V to 500V |
| Rated Output Current | 33.0 A |
| Capacity | 25.1 kVA |
| Overload Current Rating | 150% for 60 seconds, 200% for 0.5 seconds |
| Power Supply Voltage and Frequency | 3-phase, 380V to 500V, 50/60Hz |
| Protection Method | IP20 |
| Cooling Method | Forced air-cooled |
| Weight | 6.5 kg |
| Dimensions (W x H x D) | 180 mm x 310 mm x 190 mm |
