Allen-Bradley VPL-B1003T-PK12AA

Allen-Bradley Vpl-B1003T-Pk12Aa
Allen-Bradley Vpl-B1003T-Pk12Aa

Allen-Bradley VPL-B1003T-PK12AA

The Allen-Bradley VPL-B1003T-PK12AA is a servo motor from the Kinetix VP series designed for dynamic motion control applications. This motor delivers high torque and speed performance and is suitable for demanding industrial tasks. It integrates with the Kinetix 5500 and 5700 servo drives, improving overall system efficiency.

Technical Specifications:

The Allen-Bradley VPL-B1003T-PK12AA operates at 400 volts, making it suitable for handling significant power requirements efficiently. Its 100mm frame size and rated speed of 6750 RPM make it a compact and powerful option for various industrial applications.

Featuring a smooth shaft, the Allen-Bradley servo motor VPL-B1003T-PK12AA provides precise and seamless rotation. This design is crucial for applications requiring high accuracy and minimal backlash.

Equipped with a single SpeedTec DIN connector, the motor VPL-B1003T-PK12AA features a right-angle design capable of rotating 325 degrees. This configuration allows for flexible and convenient cable routing, accommodating various installation requirements. The motor VPL-B1003T-PK12AA includes an IEC metric mounting flange with free mounting holes (type FF). This ensures easy and secure attachment in diverse mounting configurations.

The motor includes three magnet stacks, contributing to its powerful and efficient performance. This design enhances the motor's torque capabilities and overall efficiency. Equipped with an 18-bit absolute multi-turn digital encoder, the VPL-B1003T-PK12AA uses the Hiperface DSL feedback protocol. This high-resolution encoder ensures precise position and speed control, crucial for applications requiring accurate motion control.

The VPL-B1003T-PK12AA is engineered for high-performance applications, featuring a rated rotational speed of 7000 RPM at its rated frequency. This high-speed capability ensures the motor can handle demanding tasks requiring quick and precise movements.

Operating Conditions:

The Allen-Bradley VPL-B1003T-PK12AA is crafted to function efficiently within 0 to 40 degrees Celsius, guaranteeing dependable performance in various environmental conditions, from cool industrial sites to moderately warm settings.

The VPL-B1003T-PK12AA is designed to operate effectively at altitudes up to 1000 meters (3280 feet) above sea level. This specification ensures that the motor maintains its performance and reliability even in higher-elevation environments.

Installation Instructions for Allen-Bradley VPL-B1003T-PK12AA:

To install the motor VPL-B1003T-PK12AA, begin by ensuring that all power sources are disconnected to maintain safety. Prepare the necessary tools and verify the cleanliness of the installation area.

Secure the motor by evenly tightening the mounting bolts. Connect the 18-bit absolute multi-turn digital encoder using the DSL protocol for precise control, and attach the SpeedTec DIN connector, which can rotate 325 degrees for optimal cable management. Adjust the SpeedTec DIN connector to the desired angle for efficient cable routing. Conduct a thorough inspection to ensure no loose parts or exposed wires.

Frequently Asked Questions:

What level of protection does the IP66 rating provide for the VPL-B1003T-PK12AA?

The IP66 rating of the motor VPL-B1003T-PK12AA indicates it is highly protected against dust ingress and powerful water jets. This means the motor is completely dust-tight, preventing particulate matter from entering and causing damage.

What is the nominal torque of the Allen-Bradley VPL-B1003T-PK12AA and what applications can benefit from this specification?

The VPL-B1003T-PK12AA has a nominal torque of 4.18 Nm, making it suitable for applications that require consistent and powerful rotational force, such as conveyor systems, automated assembly lines, and other industrial automation processes.

What is the rated frequency range of the Allen-Bradley VPL-B1003T-PK12AA?

The motor VPL-B1003T-PK12AA operates within a rated frequency range of 0 to 400 Hz, allowing it to be used in various applications that require different operating speeds and torque levels.

Product Specifications Table

Attribute Specifications
Series Kinetix VP Low Inertia Servo Motor
Voltage 480 V AC
Dimensions 100 mm Bolt Circle Frame Size, 3 Magnet Stacks
Mounting Type IEC Metric Mounting Flange
Product Status Active
Ambient Temperature Range 0 to 40°C (32 to 104°F)
Torque 4.74 Nm
Communication Interface SpeedTec Right Angle DIN Connector
Shaft Smooth
Rated Speed 6750 RPM

Allen-Bradley VPL-B1003T-PK12AA

Regular price
Sale price
$1,690.00

This product is not available for online purchase. If you would like to receive a quote please use the button below.

Eligible for Next Day Delivery All Parts Come with 24 Month Warranty New, Refurbished and Repairs Available


We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.


All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.


Payment options

We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.

Credit Terms

We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.

Description

Allen-Bradley VPL-B1003T-PK12AA

The Allen-Bradley VPL-B1003T-PK12AA is a servo motor from the Kinetix VP series designed for dynamic motion control applications. This motor delivers high torque and speed performance and is suitable for demanding industrial tasks. It integrates with the Kinetix 5500 and 5700 servo drives, improving overall system efficiency.

Technical Specifications:

The Allen-Bradley VPL-B1003T-PK12AA operates at 400 volts, making it suitable for handling significant power requirements efficiently. Its 100mm frame size and rated speed of 6750 RPM make it a compact and powerful option for various industrial applications.

Featuring a smooth shaft, the Allen-Bradley servo motor VPL-B1003T-PK12AA provides precise and seamless rotation. This design is crucial for applications requiring high accuracy and minimal backlash.

Equipped with a single SpeedTec DIN connector, the motor VPL-B1003T-PK12AA features a right-angle design capable of rotating 325 degrees. This configuration allows for flexible and convenient cable routing, accommodating various installation requirements. The motor VPL-B1003T-PK12AA includes an IEC metric mounting flange with free mounting holes (type FF). This ensures easy and secure attachment in diverse mounting configurations.

The motor includes three magnet stacks, contributing to its powerful and efficient performance. This design enhances the motor's torque capabilities and overall efficiency. Equipped with an 18-bit absolute multi-turn digital encoder, the VPL-B1003T-PK12AA uses the Hiperface DSL feedback protocol. This high-resolution encoder ensures precise position and speed control, crucial for applications requiring accurate motion control.

The VPL-B1003T-PK12AA is engineered for high-performance applications, featuring a rated rotational speed of 7000 RPM at its rated frequency. This high-speed capability ensures the motor can handle demanding tasks requiring quick and precise movements.

Operating Conditions:

The Allen-Bradley VPL-B1003T-PK12AA is crafted to function efficiently within 0 to 40 degrees Celsius, guaranteeing dependable performance in various environmental conditions, from cool industrial sites to moderately warm settings.

The VPL-B1003T-PK12AA is designed to operate effectively at altitudes up to 1000 meters (3280 feet) above sea level. This specification ensures that the motor maintains its performance and reliability even in higher-elevation environments.

Installation Instructions for Allen-Bradley VPL-B1003T-PK12AA:

To install the motor VPL-B1003T-PK12AA, begin by ensuring that all power sources are disconnected to maintain safety. Prepare the necessary tools and verify the cleanliness of the installation area.

Secure the motor by evenly tightening the mounting bolts. Connect the 18-bit absolute multi-turn digital encoder using the DSL protocol for precise control, and attach the SpeedTec DIN connector, which can rotate 325 degrees for optimal cable management. Adjust the SpeedTec DIN connector to the desired angle for efficient cable routing. Conduct a thorough inspection to ensure no loose parts or exposed wires.

Frequently Asked Questions:

What level of protection does the IP66 rating provide for the VPL-B1003T-PK12AA?

The IP66 rating of the motor VPL-B1003T-PK12AA indicates it is highly protected against dust ingress and powerful water jets. This means the motor is completely dust-tight, preventing particulate matter from entering and causing damage.

What is the nominal torque of the Allen-Bradley VPL-B1003T-PK12AA and what applications can benefit from this specification?

The VPL-B1003T-PK12AA has a nominal torque of 4.18 Nm, making it suitable for applications that require consistent and powerful rotational force, such as conveyor systems, automated assembly lines, and other industrial automation processes.

What is the rated frequency range of the Allen-Bradley VPL-B1003T-PK12AA?

The motor VPL-B1003T-PK12AA operates within a rated frequency range of 0 to 400 Hz, allowing it to be used in various applications that require different operating speeds and torque levels.

Product Specifications Table

Attribute Specifications
Series Kinetix VP Low Inertia Servo Motor
Voltage 480 V AC
Dimensions 100 mm Bolt Circle Frame Size, 3 Magnet Stacks
Mounting Type IEC Metric Mounting Flange
Product Status Active
Ambient Temperature Range 0 to 40°C (32 to 104°F)
Torque 4.74 Nm
Communication Interface SpeedTec Right Angle DIN Connector
Shaft Smooth
Rated Speed 6750 RPM
