Yaskawa CIMR-AU4A0362AAA
Yaskawa CIMR-AU4A0362AAA
The Yaskawa CIMR-AU4A0362AAA is an industrial variable frequency AC drive from the A1000 series. The drive has three-phase and single-phase inputs. The drive is designed to offer precise motor control and energy efficiency for various industrial applications.
Technical Specifications and Performance:
The Yaskawa CIMR-AU4A0362AAA VFD has input and output of 380-480 V AC. The drive will give 300 HP with a current rating of 362 Ampere in Three-phase input and 100 HP power with 124 Ampere current in single-phase input.
The drive can work on 0.01 - 400 Hz frequencies. The drive has multiple industry control methods: V/f control, Open loop vector control, Closed-loop vector control, and PM motor control. The motors that can be controlled using the drive are induction, surface permanent and interior permanent magnet.
The variable frequency drive weighs around 315 lbs and has dimensions of 31.5" x 19.69" x 13.7". The unit has a protected chassis with NEMA 1 protection, also rated as IP20 for harsh industrial environments. The drive can be mounted and installed in any orientation. It has an LCD and keypad for real-time monitoring and running smooth operation.
The Yaskawa CIMR-AU4A0362AAA drive has a high slip braking transistor of 50 HP, eliminating the need for dynamic braking resistors. It has incremental and absolute (Stegmann, Heidenhain EnDa, Resolver) feedback systems. Continuous auto-tuning feature optimises performance.
The drive has three analogue inputs of +10/-10 V DC and eight multifunctional digital input ranges of 24V DC. It has one multi-function pulse input and one multi-function relay/ pulse output. Two multi-function outputs have +10/-10V DC with 4 to 20mA of current.
The drive offers multiple built-in network interfaces for seamless integration in the industry. Modbus RTU and RS-422/485 are built-in network interfaces. Other interfaces it can support are EtherNet/IP, MECHATROLINK-II, MECHATROLINK-III and PROFINET.
Key features:
The drive offers significant energy savings through its efficient motor control algorithms. It supports various motor control methods (accuracy 0.02%), enhancing versatility and performance in different applications.it features an intuitive keypad and display for easy parameter setting and monitoring.
The drive has a speed response starting from 60Hz and torque response from a 300Hz closed loop vector. The drive can withstand harsh industrial environments with robust construction and high-quality components. The drive has built-in safety features such as overcurrent (150% for 60 sec), overvoltage, and thermal protection to safeguard the drive and the connected motor.
Applications:
The Yaskawa CIMR-AU4A0362AAA variable frequency drive is widely used in Compressors, Conveyors, Positive displacement pumps, Mixers, Hoists, General Machinery and Traction drives. It has network flexibility and high precision for complex industrial applications.
Frequently Asked Questions :
How much does the Yaskawa CIMR-AU4A0362AAACPU weigh?
The Yaskawa CIMR-AU4A0362AAA is designed to weigh 315 lbs when enclosed in NEMA 1. The dimensions are 31.5" x 19.69" x 13.7", making it a substantial unit suitable for heavy-duty applications.
What type of overload protection does the Yaskawa CIMR-AU4A0362AAA have?
The Yaskawa CIMR-AU4A0362AAACPU provides overload protection of up to 150% for 60 seconds in heavy drive mode and 120% for 60 seconds in normal drive mode. This ensures reliable performance and safeguards the drive and connected equipment under varying load conditions.
What Global Certification does the Yaskawa CIMR-AU4A0362AAA have?
The Yaskawa CIMR-AU4A0362AAA drive holds UL, CSA, CE, C-Tick, and RoHS Global certifications. These certifications attest to the drive's high standards of safety, environmental compliance, and overall reliability in global markets.
Product Specifications Table
| Attribute | Specifications |
|---|---|
| Voltage output | 480V |
| Current output | 362A |
| Manufacturer | Yaskawa |
| 200:1 | |
| Analog input | 03 |
| Ambient temperature | -10 to +50 degree Celsius |
| Series | A1000 |
| Enclosure Protection | NEMA 1 |
| Feedback | Incremental / Absolute |
| Weight | 315 lbs |
