Yaskawa CIMR-PU4A0058FAA

The Yaskawa CIMR-PU4A0058FAA is a Variable Frequency Drive used to control the fan and pump. It is specifically designed for variable torque application. The drive belongs to the P-1000 series that supports a variety of network interfaces and control options. It is a reliable and efficient solution for complex industrial applications.

Technical Specifications:

The Yaskawa CIMR-PU4A0058FAA drive can operate on single-phase and three-phase. It provides 40 HP of power and a current of 58 Amp when used on a three-phase current. Provides power of 15 HP and a current of 21 Amp while working on Single-phase current.

The drive has input voltage ranging from 380-480V AC. The output frequency range is 0.1 HZ to 400 Hz for precise control of the induction motors. The drive has a V/Hz (scalar) control method that is in demand in the industry. The drive has a DC injection braking system to stop the motors.

The drive has advanced safety features. It can take 150% load for about 60 s without damaging the drive. The drive can be easily mounted on the wall and panel with screws. The built-in display has a 5-line and 16-character display with a keypad for starting, stopping, resetting, timer and speed changes. The drive offers a multiple-unit system for easy integration and quick setup.

The Yaskawa CIMR-PU4A0058FAA variable drive working temperature is -10 °C to +40 °C while the storage temperature ranges from -20°C to 60°C. The drive has a net weight of 66 lbs, a Height measure of 18.31 ", a width measure of 10 ", and a depth measure of 10.16 ". The drive is enclosed in a NEMA 1 case for industrial heat and humidity.

Standard Input/Output:

The drive has standard input and output for different operations varying by industries. The drive has eight multi-functional 24V DC digital inputs and three multifunctional 0-10V DC analogue inputs, the current range being 4-20mA. The drive has one multi-functional pulse input and one fault relay output in Form C.

The Yaskawa CIMR-PU4A0058FAA drive has one multi-functional relay in Form C and two multi-function relay outputs (form A). Two multi-function analogue outputs range from 0 to +-10V DC with a 4-20mA current. The sensor feedback has a power supply of 24V DC with 150 mA of current. The drive has a 120V converter for eight standard digital inputs.

Networking Interface:

The drive has many networking interfaces for seamless integration into industry working systems. The drive can support industrial communication such as Modbus RTU (built-in), DeviceNet, EtherNet/IP, Modbus TCP/IP, PROFIBUS-DP, and PROFINET. Building automation networks (BAS) that are supported in the series are BACnet, Lonworks, Metasys (N2), and Apogee (P1).

Frequently Asked Questions:

How much Yaskawa CIMR-PU4A0058FAACPU weighs?

The Yaskawa CIMR-PU4A0058FAA drive has a net weight of 66 lbs, a Height measure of 18.31 ", a width measure of 10 ", and a depth measure of 10.16 ".

What is power output of Yaskawa CIMR-PU4A0058FAA?

The Yaskawa CIMR-PU4A0058FAACPU provides 40 HP of power and a current of 58 Amp when used on a three-phase current. Provides power of 15 HP and a current of 21 Amp on Single-phase current.

How many Global Certifications Yaskawa CIMR-PU4A0058FAA has?

The Yaskawa CIMR-PU4A0058FAA has five global certifications: UL, CSA, CE, RoHS, and C-Tick. These certifications ensure compliance with international safety and environmental standards.
