Description

Yaskawa CIMR-PU4A0072FAA

The Yaskawa CIMR-PU4A0072FAA Variable Frequency Drive P1000 AC Drive 380-480 VAC Variable Torque with input options of either Three-phase or single-phase Industrial VFD. These drives are designed for industrial applications requiring reliability, flexibility, and high performance.

Technical Description:

Yaskawa CIMR-PU4A0072FAA Variable Frequency Drive P1000 AC Drive 380-480 VAC Variable Torque with input options of either Three Phase: 50 Hp 72 Amp or (Single Phase: 20 Hp 27 Amp) Industrial VFD. Nema 1 Chasis 20.28" x 10.98" x 10.16" includes a configurable LCD and keypad with built-in backup memory.

It has eight programmable digital inputs, of which one can be used as a pulse input, two programmable analog outputs, three analog inputs, and four digital outputs. It recommends Line and Load Reactors for all VFDs. Line (Input) Reactors protect the VFD from input power disturbances that can trip and harm drives while reducing harmonics generated that return into the line.

The A1000 series VFD is truly a multifaceted equipment that can easily assist in the control of both induction as well as synchronous motors and has a 400V class input voltage with an excellent control of the motors according to the required frequencies. It offers power and steering control techniques for enhanced efficiency and power in performing operations.

The CIMR-PU4A0072FAA comes with a strong construction which makes it perfect for use in industries which are full of dust or other harsh conditions and does not affect the reliability of the device. With overload capacity it has power of 150% rated current for 1minute and 200% for 3 seconds that gives enough torque to handle tough jobs. New safety features like Safe Torque Off (STO) are incorporated to make the secure operation.

Attachments Specifications:

A number of connection possibilities are available with the Yaskawa CIMR-PU4A0072FAA to expand the main application of the controller. Some of the features are flexible communication modules for Ethernet or Modbus to allow integration, a keypad to control the settings, and safety modes, including Safe Torque Off (STO). Also, it has powerful terminal blocks for wiring connections that make it sturdy and firm to ensure safe usage in rough industrial climates.

Standard Safety Precautions:

Standard safety measures that should be taken include making sure the CIMR-PU4A0072FAA control panel is grounded correctly to avoid electric shock hazards and conform to all electrical codes of the region/country. One has to always switch off the power supply before installing or making some repairs to the machine to prevent the occurrence of accidental deaths.

Some essential functionalities include the Safe Torque Off (STO), which enables power to the drive/motor team to shut down safely in cases of emergencies. Practical maintenance requires a consistent check on the drive for scratches, dents, or any signs of wear and, generally, should not be exposed to water or heat. It is essential to ensure that there is an adequate flow of air as this is another factor that causes foods to catch an early morning sun.

Frequently Asked Questions:

What motor types are compatible with the CIMR-PU4A0072FAA?

The CIMR-PU4A0072FAA supports both induction motors and synchronous motors, offering versatile control for various industrial applications. This compatibility ensures flexibility in choosing the appropriate motor for your specific needs, enhancing overall system performance.

What safety features does the CIMR-PU4A0072FAA include?

This VFD includes advanced safety features such as Safe Torque Off (STO) to ensure secure operation and prevent unintended motor startup during maintenance. Additionally, it offers comprehensive protection against overcurrent, overvoltage, and overheating, safeguarding both the motor and the VFD itself.

What communication protocols are supported by the CIMR-PU4A0072FAA?

The CIMR-PU4A0072FAA supports various communication protocols, including Ethernet and Modbus, for seamless integration into complex control systems. This wide range of communication options facilitates efficient data exchange and enhances connectivity with other industrial devices.

Product Specifications Table

Attribute	Specifications
Manufacturer	Yaskawa
Input Voltage	400V class
Output Frequency Range	0.01 to 400 Hz
Motor Compatibility	Induction and synchronous motors
Control Methods	Open Loop Vector Control, Closed Loop Vector Control, V/f Control
Overload Capacity	150% for 60 seconds, 200% for 3 seconds
Safety Feature	Safe Torque Off (STO)
Communication Protocols	Ethernet, Modbus
User Interface	Intuitive keypad with clear display
Installation	Secure wiring connections with terminal blocks
