Yaskawa CPS-12N
We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Payment options
We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.
Credit Terms
We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.
Description
Yaskawa CPS-12N
The Yaskawa CPS-12N is a dependable DC power supply unit tailored for advanced manufacturing and CNC applications. Part of the Yasnac series, it ensures consistent performance, boosting the efficiency and reliability of machine tools and automation systems.
Technical Features:
The Yaskawa CPS-12N power supply accommodates input voltages of 200 V-AC, 220 V-AC, and 230 V-AC, enabling global use and compatibility with different electrical standards. This adaptability ensures reliable performance in various industrial settings. The CPS-12N offers versatile output voltages of 5 V-DC, 12 V-DC, and 24 V-DC. This range accommodates various applications, from precise CNC machinery control to powering essential industrial components, ensuring consistent and stable operation.
The Yaskawa YASNAC CPS-12N DC power supply unit includes five connectors labeled CN01, CN02, CN03, CN04, and CN05. These connectors facilitate easy integration and seamless installation across various industrial systems.
Capacitors within the CPS-12N are crucial electrical components. They achieve maximum capacitance through narrow separation between large conductor areas, often called "plates." This terminology originates from early capacitor construction methods.
Ambient Conditions:
The Yaskawa CPS-12N is designed to function optimally within a specific range of environmental conditions. The ideal operating temperature for this power supply unit ranges from 0°C to 50°C (32°F to 122°F).
The recommended operating humidity for the CPS-12N is between 20% and 85% non-condensing. Maintaining humidity within this range prevents moisture buildup, lowering the risk of short circuits and other electrical issues.
The CPS-12N is built to withstand certain levels of vibration and shock, making it suitable for industrial environments where such conditions are common. It can tolerate vibrations up to 0.5G in a frequency spectrum of 10Hz to 55Hz.
Installation Instructions for Yaskawa CPS-12N:
Before beginning the Yaskawa CPS-12N power supply installation, ensure you have all the necessary tools and safety equipment. Verify that the CPS-12N is compatible with your system and meets the required specifications.
Double-check all connections and mounting hardware before powering up the CPS-12N to ensure no short circuits or exposed wires. Power up the unit and observe the initial startup sequence, checking for error indicators or abnormal behavior.
Once powered on, perform a series of tests to verify correct functionality. Measure the output voltages to ensure they are within the specified ranges. Adjust settings or calibration parameters as necessary according to your system requirements.
Conduct a final inspection to confirm all connections are secure and that there are no signs of overheating or other issues. Ensure the CPS-12N operates within its specified parameters and provides stable power to your system.
Frequently Asked Questions:
How much does the Yaskawa CPS-12N power supply unit weigh?
The CPS-12N power supply unit weighs 3.40 lbs, allowing easier handling and installation. Its light weight makes it convenient for technicians to integrate into various industrial setups with minimal physical effort.
What are the dimensions of the CPS-12N power supply unit?
The CPS-12N power supply unit has dimensions of 5.50" (H) x 3.00" (W) x 10.50" (D). Its compact size facilitates seamless integration into confined spaces within industrial control panels or machinery, offering versatility for various configurations.
At what altitude can the Yaskawa CPS-12N operate efficiently?
The Yaskawa CPS-12N is engineered to operate efficiently at altitudes up to 1000 meters (3280 feet) above sea level. This altitude range ensures optimal performance and effective cooling, which is crucial for reliable operation in diverse environmental conditions.
Product Specifications Table
| Attribute | Specifications |
|---|---|
| Series | YASNAC |
| Voltage | Input Voltage: 200/220/230 VAC |
| Dimensions | 5.50" (H) x 3.00" (W) x 10.50" (D) |
| Frequency Range | 50/60 Hz |
| Weight | 3.40 lbs |
| Operating Altitude | 1000 meters above sea-level |
| Product Status | Dicontinued by Manufacturer |
| Manufacturer | Yaskawa |
| Ambient Temperature Range | 0°C to 50°C |
| Power Rating | 300 VA |
