Yaskawa SGMGH-1EDCA61

The Yaskawa SGMGH-1EDCA61 is a high-performance servo motor that comes in the Sigma II series by Yaskawa Electric Corporation. High accuracy in providing reliable energy makes it applicable in many industries. It is adequately built with intricate functions that make it capable of functioning optimally in high-risk areas.

Technical Description:

The Yaskawa SGMGH-1EDCA61 belongs to the Sigma II line, and it is an AC servo motor designed for heavy-duty operations in various industrial sectors. It has a 1.0 kW power rating, can deliver a lot of torque, and has speed control suitable to an array of tasks.

The device has a rated speed of 1,500 RPM, which is the speed range at which it is capable of working when it is required to do so, and has a maximum speed of 3,000 RPM, ideal for smooth motion control at higher speeds as well as rapid motion control for slow and steady movement.

In Yaskawa SGMGH-1EDCA61, the system uses a 20-bit absolute encoder that helps read positional data in detail and deliver smooth movements. This feature of giving feedback enables the motor to improve its complex task automation and minimize any probable errors, which in turn boosts the overall performance of the system.

Operating on industrial standards that call for efficiency and reliability, the motor is designed with an Ingress Protection rating of IP67, which makes it safe for use in areas that are highly likely to be exposed to dust and water. They use high-quality components and construction materials.

Attachments Specifications:

The Yaskawa SGMGH-1EDCA61 servo motor includes several attachments. It is equipped with a 20-bit absolute encoder, which enables it to deliver increased feedback resolution during positioning. The motor also has a power and signal cable set that is well-built, which ensures a firm connection of cables and is easy to install. The motor also uses a flange and a shaft key for easy mechanical interfacing of the equipment to complex systems.

Standard Safety Precautions:

When using the Yaskawa SGMGH-1EDCA61 servo motor, it is essential to follow specific safety measures that would lead to the effective use of the equipment. It is always important to disconnect power when there is installation or wiring, repair, or checking circuits to avoid getting an electric shock.

It is essential to wear proper protective wear, such as gloves and goggles, during handling. Check whether the motor is earthed correctly or not before going for the operation to prevent electrical shock. Comply with all the local and national electrical codes of installation for the equipment to work efficiently. Although the devices have an IP67 rating, they should not be exposed to water and moisture and should be provided with proper ventilation to avoid overheating. The motor and cables shall also be checked for damages normally.

Frequently Asked Questions:

What is the power rating of the Yaskawa SGMGH-1EDCA61 servo motor?

The Yaskawa SGMGH-1EDCA61 servo motor has a power rating of 1.0 kW, making it suitable for various industrial automation applications requiring substantial torque and speed control.

What type of encoder does the SGMGH-1EDCA61 use?

The SGMGH-1EDCA61 is equipped with a 20-bit absolute encoder, providing high-resolution feedback for precise positioning and smooth operation in complex automation tasks.

What is the protection rating of the Yaskawa SGMGH-1EDCA61?

The Yaskawa SGMGH-1EDCA61 has an IP67 protection rating, which means it is highly resistant to dust and can withstand immersion in water up to 1 meter for 30 minutes. This level of protection makes it suitable for demanding industrial environments.
