Yaskawa SGMGH-1EDCA6C

The SGMGH-1EDCA6C Servo Motor by Yaskawa is a high-performance motor designed for demanding industrial applications. This motor features a rated output of 15.0 kW, making it suitable for various high-power tasks. It delivers a rated torque of 845 lb-in, ensuring efficient performance under load. Additionally, the motor provides an instantaneous peak torque of 1960 lb-in, allowing it to handle sudden spikes in demand effectively.

Electrical Specifications:

Operating at a rated current of 37.2 A, the SGMGH-1EDCA6C can maintain a consistent performance. The motor can handle an instantaneous maximum current of 85 A, which is critical for applications requiring rapid acceleration or deceleration. With a rated speed of 1500 rpm, this servo motor ensures precise control and smooth operation. It can reach a maximum speed of 2000 rpm, providing the flexibility needed for various applications.

The torque constant of the SGMGH-1EDCA6C is 23.4 (lb-in)/A, indicating its efficiency in converting electrical current to torque. The moment of inertia is 279 lb-in-s² x 10?³, which contributes to the motor€™s stability and responsiveness. The motor boasts a rated angular acceleration of 3030 rad/s², enabling quick and accurate movements in high-speed applications.

One of the key electrical specifications of the SGMGH-1EDCA6C is its operating voltage of 400V. This motor is classified under Insulation Class F, which ensures it can withstand high temperatures. The motor€™s insulation can endure a voltage of 1800Vac for one minute, demonstrating its robustness. It has an insulation resistance of 500VDC with a minimum of 10M?, ensuring safety and reliability.

Mechanical Specifications:

Mechanically, the SGMGH-1EDCA6C is built to last. It features a totally enclosed, self-cooled enclosure with an IP67 rating. This design protects the motor from dust and water ingress, making it suitable for harsh environments. The motor operates within an ambient temperature range of 0 to 40°C, ensuring it performs optimally in a variety of settings. The excitation is provided by a permanent magnet, which enhances the motor€™s efficiency and reliability.

The mounting method for the SGMGH-1EDCA6C is via a flange, which ensures secure and stable installation. The motor uses a direct drive method, which simplifies the mechanical setup and improves overall efficiency. Environmental conditions for this servo motor include an ambient humidity range of 20% to 80%, with no condensation, ensuring reliable operation in various climates.

Performance Characteristics:

The SGMGH-1EDCA6C features an inertia time constant of 1 ms and an inductive time constant of 26.2 ms. These specifications contribute to the motor€™s rapid response and precise control capabilities. The combination of these time constants and the high rated angular acceleration makes this motor suitable for applications requiring high-speed precision.

The robust design and high torque capabilities of the SGMGH-1EDCA6C ensure that it can handle demanding industrial tasks with ease. Its construction is focused on durability, making it a reliable choice for long-term industrial use.

Frequently Asked Questions:

What is the rated output of the SGMGH-1EDCA6C Servo Motor?

The SGMGH-1EDCA6C Servo Motor by Yaskawa has a rated output of 15.0 kW, making it suitable for various high-power tasks in demanding industrial applications.

What are the environmental conditions for operating the SGMGH-1EDCA6C?

The motor operates within an ambient temperature range of 0 to 40°C and an ambient humidity range of 20% to 80%, with no condensation, ensuring reliable operation in various climates.

What type of enclosure does the SGMGH-1EDCA6C feature?

The SGMGH-1EDCA6C has a totally enclosed, self-cooled enclosure with an IP67 rating, except for the through-sections of the shaft, protecting it from dust and water ingress.
