Yaskawa SGMGH-30D2A6C

The Yaskawa SGMGH-30D2A6C Servo Motor is designed for precision applications. It has a rated speed of 1500 rpm. The maximum speed reaches up to 3000 rpm. The torque constant is 14.7 (lb-in)/A or 1.66 (N-m)/A. Its moment of inertia is 40.7 lb-in-s² x 10?³ (46.0 kg-m² x 10??).

Performance Specifications:

This servo motor model has a rated power rating of 75.3 kW/s. The rated angular acceleration is 4050 rad/s². The motor operates at a voltage of 400V. It belongs to the insulation class F.

It can withstand a voltage of 1800Vac for one minute. The insulation resistance is 500VDC with a minimum of 10M?. The ambient temperature range lies between 0 to 40°C. The ambient humidity range is from 20% to 80% without condensation.

The excitation type is a permanent magnet. The mounting method used is flange mounting. The drive method is a direct drive. The servo motor's rated output is 2.9 kW.

Technical Details:

The rated torque is 165 lb-in (18.6 N-m). The instantaneous peak torque reaches 404 lb-in (45.1 N-m). The rated current is 11.9 Arms. The instantaneous maximum current is 28 A. The inertia time constant is 2.0 ms. The inductive time constant is 12.3 ms. The product code SGMGH-30D2A6C identifies this Yaskawa servo motor. The SGMGH-30D2A6C offers robust performance in various industrial applications.

It ensures reliable operation with high precision. This servo motor's construction supports high durability. Its design includes advanced insulation for safety. The permanent magnet excitation improves efficiency.

The flange mounting ensures secure installation. The direct drive method offers better control. Yaskawa€™s servo motor model SGMGH-30D2A6C is built to handle demanding tasks. It is suitable for environments within its specified temperature and humidity ranges.

Operational Efficiency:

The high rated torque allows for powerful performance. The peak torque capability ensures handling of sudden loads. The voltage specifications ensure compatibility with standard industrial power systems.

The insulation resistance enhances operational safety. The withstand voltage specification confirms its durability. The SGMGH-30D2A6C servo motor is designed for consistent performance. Its rated and maximum speeds support various applications.

The torque constant and moment of inertia provide smooth operation. The rated power rating indicates its capability for sustained output. The rated angular acceleration ensures quick response times.

The motor's excitation and mounting methods contribute to its reliability. This servo motor's technical specifications make it suitable for precision tasks. The high rated output and torque enhance its utility.

The insulation class F and withstand voltage ensure safety under different conditions. The product code and name should be referenced for accurate identification. The Yaskawa servo motor SGMGH-30D2A6C is a reliable and powerful component in industrial setups. Its advanced features make it ideal for high-performance applications.

Frequently Asked Questions:

What is the rated speed and maximum speed of the Yaskawa SGMGH-30D2A6C Servo Motor?

The Yaskawa SGMGH-30D2A6C Servo Motor has a rated speed of 1500 rpm and a maximum speed of 3000 rpm. These specifications make it suitable for precision applications that require high-speed operations.

What is the torque constant and moment of inertia for the SGMGH-30D2A6C Servo Motor?

The torque constant for the SGMGH-30D2A6C Servo Motor is 14.7 (lb-in)/A or 1.66 (N-m)/A. The moment of inertia is 40.7 lb-in-s² x 10?³ or 46.0 kg-m² x 10??, ensuring smooth and efficient operation.

What are the ambient operating conditions for the Yaskawa SGMGH-30D2A6C Servo Motor?

The ambient operating temperature range for the SGMGH-30D2A6C is from 0 to 40°C, and the ambient humidity range is from 20% to 80% without condensation. These conditions ensure reliable performance in various environments.
