Description

Yaskawa SGMGV-30ADC6C

The SGMGV-30ADC6C servo motor is manufactured by Yaskawa. It features a continuous time rating. The vibration class for this motor is V15. The insulation resistance is 500 VDC, 10 M? minimum. It uses a permanent magnet for excitation. The mounting method is flange-mounted. It has a thermal class of F. It withstands a voltage of 1500 VAC for one minute in the 200-V class.

Environmental and Physical Specifications:

The enclosure of the SGMGV-30ADC6C is totally enclosed and self-cooled, rated at IP67, except for the shaft opening. This rating ensures the motor is well-protected against dust and can withstand temporary immersion in water. The drive method for this servo motor is direct drive for ensuring efficient transmission of power. The rotation direction is counterclockwise with a forward run reference when viewed from the load side.

Holding Brake Specifications:

The SGMGV-30ADC6C servo motor includes specific holding brake specifications. It features a holding torque of 43.1 Nm. This high holding torque ensures the motor can maintain its position accurately when powered off, which is crucial for applications requiring precise control.

It supports an allowable load moment of inertia five times the rotor moment of inertia. This capability allows for flexibility in various load conditions. There is a 1470 N permissible radial load (Fr) and a 490 N permissible thrust load (Fs). These specifications indicate the motor's capacity to handle significant mechanical stresses during operation. The mass of the servo motor is 13.5 kg, which balances performance with manageable weight for installation.

General Specifications:

The SGMGV-30ADC6C servo motor is designed for high-power applications, and one of its main specs is its 2.9 kW rated output. With a rated torque of 18.6 Nm, it can provide substantial force for a variety of mechanical operations. It has 45.1 Nm instantaneous peak torque that allows the motor to handle sudden, high-torque demands effectively.

The rated current for this servo motor is 23.8 A, and the instantaneous maximum current is 56 A. These current ratings ensure that the motor can operate efficiently under different load conditions. The rated speed is 1500 min-1, with a maximum speed of 3000 min-1. This wide speed range offers versatility in different applications.

It has a torque constant of 1.70 Nm/A, which defines the motor's ability to convert electrical current into torque effectively. The rotor moment of inertia without the holding brake is 46 x 10^-4 kg·m², indicating the motor's responsiveness to control inputs.

The rated power rate without holding brake is 75.2 kW/s, showcasing the motor's high power delivery capacity. The rated angular acceleration is 4040 rad/s² without holding brake. This acceleration rates highlight the motor's ability to rapidly change speeds, which is essential for dynamic applications.

Frequently Asked Questions:

What are the load and mechanical specifications of this servo motor?

The SGMGV-30ADC6C supports an allowable load moment of inertia five times the rotor moment of inertia. It can handle an allowable radial load (Fr) of 1470 N and an allowable thrust load (Fs) of 490 N, making it robust for various mechanical stresses.

What is the rated output of the SGMGV-30ADC6C servo motor?

The SGMGV-30ADC6C servo motor, manufactured by Yaskawa, has a rated output of 2.9 kW. This qualifies it for high-power applications in a variety of industrial situations which require substantial force and precision.

What is the holding torque of the SGMGV-30ADC6C's holding brake?

The holding brake of the SGMGV-30ADC6C servo motor features a holding torque of 43.1 Nm. This high holding torque ensures precise position maintenance when the motor is powered off, essential for applications needing accurate control.

Product Specifications Table

Attribute	Specifications
Rated Output	2.9 kW
Rated Torque	18.6 Nm
Instantaneous Peak Torque	45.1 Nm
Rated Speed	1500 min-1
Max. Speed	3000 min-1
Insulation Resistance	500 VDC, 10 M? min.
Ambient Temperature	0 to 40?C
Enclosure	Totally enclosed, self-cooled, IP67 (except for shaft opening)
Mass	13.5 kg
Allowable Radial Load (Fr)	1470 N
