Allen-Bradley 1762-IF4
We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Payment options
We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.
Credit Terms
We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.
Description
Industrial Automation Co. is NOT an Authorized Rockwell Distributor - we have our own unique inventory and sourcing relationships. Review our Reseller notice here.
- 1762IF4
- INPUT MODULE
- 4 POINT
- ANALOG
- 4/20 MA
- 5/24 VDC
- MICROLOGIX
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Understanding the Allen-Bradley 1762-IF4
The Allen-Bradley 1762-IF4 is a four-channel analog input module with a Delta-Sigma converter. It is compatible with MicroLogix 1100, 1200, and 1400 PLCs. The device supports 4-20 mA and -10 to 10V DC signals. It receives information and communicates on 5 to 24 volts of DC power via the 1762 bus interface. The module's compact design allows it to integrate into control systems with limited space easily.
Key Benefits and Features
The 1762-IF4 module features a wide range of benefits, such as finger-safe terminal blocks for I/O wiring. LED indicators show status information about power, communication, and fault conditions. A field-upgradeable flash operating system ensures operators are always up to date with the latest features without replacing hardware.
Users can expand the I/O count with compact I/O modules, allowing larger control systems and greater application flexibility at a reduced cost with a lower parts inventory. If used with MicroLogix 1100, you can add up to four expansion modules; if MicroLogix 1200, six; and if MicroLogix 1400, seven.
Technical Specifications
Each of the 1762-IF4's four channels is configurable. The modules have a common mode voltage range of -27 to 27 volts. Other technical specifications include:
- Analog operating voltage range
- Normal: -10 to 10 volts DC
- Full-scale: -10.5-to-10.5-volt DC
- Analog operating current range
- Normal: 4 to 20 mA
- Full-scale: -21 to 21 mA
- Operating temperature range: -20°C (-4°F) to 65 °C (149 °F)
- Weight: 0.53 lbs.
- Dimensions: 3.54" x 3.43" x 1.57"
Allen-Bradley 1762-IF4 Applications
The 1762-IF4 is ideal for a broad array of industrial environments. Although compact, it is powerful enough for a variety of applications, such as:
- Food and beverage
- Manufacturing
- Material handling
- Packaging
Installation and Configuration of 1762-IF4
The installation should be in a non-hazardous environment that is clean and dry. The device supports a 2-wire, 3-wire, or 4-wire transmitter configuration. Always remove power and prevent electrostatic discharge to avoid damage. The operator can select the input signal type through the provided DIP switches. For expansions, the installer should use the ribbon cable connected by pin contacts installed on the front panel of every 1762-IF4. The module can be DIN-rail or direct-panel mounted.
Fast Shipping & Outstanding Customer Service
Purchase Industrial Replacement Parts from Industrial Automation Co.
Industrial Automation Co. is the global leader in automation replacement parts, including the 1762-IF4. Backed by our unparalleled turnaround times and exceptional customer service, we ensure you get the components you need when you need them. Order your modules today and see the difference we make.
TECHNICAL SPECIFICATIONS
| Manufacturer | Rockwell Automation |
| Brand | Allen-Bradley |
| Part Number/Catalog No. | 1762-IF4 |
| Series | MicroLogix 1200 |
| Product Type: | Analog Input Module |
| Analog Normal Operating Voltage | -10.5 to 10 Volts DC |
| Product Family: | MicroLogix |
| Inputs | 4 Differential (Bipolar) |
| Voltage signal normal ranges: | '-10.5 … +10.5V dc |
| Current signal normal ranges: | 4 … 20 mA |
| Current signal full range: | -21 … +21 m |
| No. of Inputs: | Four (4) Differential (Bipolar) |
| Mounting Type | DIN Rail or Panel |
| Status Indicator | Single source LED |
| Recommended Cable | Belden 8761 (shielded) |
| Shipping Weight | 8.28 ounces |
| UPC | 10611320152125 |
| Enclosure Type Rating | IP20 |
| Converter | Delta-Sigma |
| Resolution: | 15 bit |
| Repeatability: | ±0.12% |
| Dimensions | 90 x 87 x 40.4 millimeters |
