Allen-Bradley 1764-LSP

allen-bradley-1764-lsp

Allen-Bradley 1764-LSP

$0.00

This product is not available for online purchase. If you would like to receive a quote please use the button below.

Request a Price Quote
Eligible for Next Day Delivery All Parts Come with 24 Month Warranty New, Refurbished and Repairs Available

We can ship via UPS, FedEx, and USPS. We can ship on customers' accounts as well. International delivery available via UPS and DHL. In stock items typically ship same day.


All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.


Payment options

We accept all major credit cards. Arrangements can be made for Wire Transfers and PayPal payments.

Credit Terms

We understand that credit is a necessary part of business. We offer NET 30 terms to established companies.

Description

The Allen-Bradley 1764-LSP is a MicroLogix 1500 processor that features a 7KB integrated memory, partitioned into 3.65KB for user programs and 4KB for user data, allowing for versatile configuration of function files and system resources. It includes a non-isolated RS-232-C port supporting ASCII, DF1, DH-485, and Modbus protocols for easy communication with HMIs, SCADA, and other devices, and offers robust connectivity options with eight local and sixteen expansion I/O modules. With approximately 1 ms program execution time for a 1K-word program and support for up to 512 inputs and outputs, the 1764-LSP is well-suited for small machine or process applications, although it is now available as a spare part, having been discontinued in 2017.


Buying Options
Buying Options

All products are covered by Industrial Automation Co.'s 2-Year Warranty.

Condition SKU Price Warranty Availability Quantity Purchase
Surplus Original Box 1764-LSP-FS 2 Year Extended Warranty Call for Availability Call for Availability (877)-727-8757
Quick Repairs and Great Service

Send in your item for a free evaluation and repair quote. Use our RMA form or email a repair request to service@iac.us.com , and we will contact you to assess your situation and offer shipping information.

Quick Search

All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.


TECHNICAL SPECIFICATIONS

ManufacturerRockwell Automation
BrandAllen-Bradley
Part Number/Catalog No.1764-LSP
SeriesMicroLogix 1500
Product Family:MicroLogix
FunctionProcessor Unit
Product Type:MicroLogix Controller
Memory7.6 Kb
Communication PortsDH-485, Modbus, DF1, and ACSII
Supported Base Units:1764-AWA; 1764-BWA; 1764-BXB
Enclosure TypeIP20
Power supply:MicroLogix Bus
Output SourceRelay Port and DC FET
Heat Dissipation:1.9 Watts
SoftwareRSLogix 500
Bus Current Draw:380 MA
Digital Trim Potentiometers2 built-in
Communication Port:1; RS232
Compatible Memory Module1764-MM1, 1764-MM2, 1764-MM3
User Memory:Series B; 12K (8K Program; 4K Data)Series C: 14K (10K Program; 4K Data)
Compatible Real Time Clock1764-RTC
Communication Protocol:Channel 0: DF1, DH485, Modbus, ASCII
RS232 Topology:Point to point
UPC10611320023630
Support for removal under power:28
Product Lifecycle Status*Discontinued/Obsolete
Expansion I/O:512

*The Allen Bradley 1764-LSP has been discontinued by the manufacturer, however we specialize in obsolete parts and can likely still supply surplus and/or refurbished replacement 1764-LSP units instead of migration.
