Indramat HDS03.2-W075N-HS12-01-FW
Indramat HDS03.2-W075N-HS12-01-FW
The drive HDS03.2-W075N-HS12-01-FW is a model of servo drive controller manufactured by Bosch Rexroth. This device is part of the IndraDrive series and is designed to control the motion of servo motors. The company includes many equipment and products in such control applications. Over the years, Indramat has built a strong reputation for innovation and excellence in industrial automation.
Technical Specifications :
For the drive HDS03.2-W075N-HS12-01-FW, the firmware is not included with this drive and needs to be ordered separately. The "FW" in the model number shows that the firmware can be specified or updated as per requirements. This flexibility allows for tailored software solutions.
It has a short circuit current rating of 42,000 amperes (A) RMS. The power input voltage ranges between 530 and 670 volts. Its maximum input current under UL standards is 37A, while the maximum output current is 40A. The device can have an operating output frequency of up to 1000 Hz.
It stands 498 mm tall, has a depth of 308 mm, and a width of 100 mm. These measurements make it compact and suitable for various installation spaces. Additionally, this device can deliver a maximum output voltage of 500 volts. This high output voltage ensures powerful performance for demanding applications.
The drive consisted of a rated control voltage input of 26 volts with a tolerance of ±2% with maximum power dissipation of 220 watts at continuous current, and it weighs around 11 kilograms, making it both efficient and manageable in weight for many domains.
Operational and Installation Parameters:
Ensure at least 100mm of space below the device for proper ventilation. Use only 60/75 °C copper wire for field wiring, specifically class 1 or its equivalent. Make sure that the wiring material, as well as the drive, can handle temperatures between 45 to 55 degrees Celsius.
The drive can have a humidity bearing up to 90% and allows the use of an independent pair of shielded wires to correctly detect a temperature. It is an essential factor to differ among the positioning of the units when connections are built between the control system and the drive during the operation and installation process.
Safety Precautions:
Only professional persons should work with the device, and people who are heart pacemakers or metal implanted should be restricted from working in these areas. This includes where electrical equipment and components are installed, operated, or tested. Additionally, areas, where parts of motors with permanent magnets are stored, fixed, or assembled are also restricted.
It is necessary to prevent electrostatic charging near the drive to protect against damage. Touching the equipment with wet hands shouldn't be done as it will result in a severe injury or even lead to death.
Frequently Asked Questions :
What is the output current rating in drive HDS03.2-W075N-HS12-01-FW?
The Indramat drive with FW consumes about 40 amperes of maximum output current. This high output current rating ensures robust performance for demanding industrial applications.
What rating of control input voltage does the drive HDS03.2-W075N-HS12-01-FW need?
The drive has a fixed voltage value of 26V with a positive and negative tolerance of 2% for proper functioning. This precise control input voltage is critical for the drive's optimal operation and stability.
What is the required three-phase frequency for HDS03.2-W075N-HS12-01-FW?
The Indramat drive requires an output frequency of 1000 Hz for the desired operation. This high-frequency requirement is essential for achieving the drive's intended performance and efficiency.
Product Specifications Table
| Attribute | Specifications |
|---|---|
| Manufacturer | Indramat Rexroth |
| Series | HDS |
