Schneider Electric ATV212HD45N4

A high-performance variable speed drive from the 212 series, the Schneider Electric ATV212HD45N4 is specifically engineered for HVAC applications. The drive is designed to seamlessly integrate into building management systems and optimize energy efficiency, providing advanced communication capabilities and robust performance. It is an optimal solution for optimizing energy consumption and controlling motor speed in a variety of industrial and commercial environments.

Technical Details:

The 45 kW ATV212HD45N4 is ideal for high-performance applications. It operates from 380-480 V AC, making it suitable for many electrical situations. This drive supports three-phase setups for optimal performance and power distribution. The continuous current rating of 65.9 A and maximum short-term current of 83.8 A ensure peak load capacity.

The ATV212HD45N4 model with an output frequency range of 0.5 to 200 Hz, precisely controls motor speed. Its IP21 designation protects against solid objects larger than 12 mm and vertically falling water drops, making it suitable for indoor use. This Schneider Electric's drive to comply with RoHS and REACh shows its commitment to sustainability. The 21-kg drive is 241 mm wide, 550 mm tall, and 245 mm deep. These small dimensions make installation easy in various settings.

Heat sink assembly improves ATV212HD45N4 thermal management. It works well in ambient air temperatures from 14 °F to 104 °F without derating and up to 50 °C with a derating factor. According to IEC 60068-2-27 requirements, the drive can endure 15 gn for 11 ms, ensuring its industrial durability.

Performance and Accuracy:

With a ±0.6% accuracy for VIA and VIB under temperature variations of up to 60 °C and a ±1% accuracy for FM under similar conditions, the ATV212HD45N4 boasts high accuracy levels. These accuracy specifications guarantee consistent performance under a variety of environmental conditions. The drive allows for precise control over motor speed changes by supporting acceleration and deceleration gradients that are linearly adjustable separately from 0.01 to 3200 seconds.

Advanced Features and Applications:

The drive's switching frequency can be adjusted from 6 to 16 kHz to suit the application. It can operate from 8 to 16 kHz with a derating factor, making it suitable for noise-sensitive applications. Automatic load-dependent acceleration and deceleration simplify configuration and improve performance on the ATV212HD45N4.

The Schneider Electric ATV212HD45N4 improves motor control and energy efficiency in HVAC systems. It supports Modbus, BACnet, APOGEE FLN P1, MetaSys N2, and LonWorks as standard and optional protocols. This ensures remote monitoring and control and interoperability with modern building management systems.

Frequently Asked Questions:

What are the continuous current rating and the IP rating of the Schneider Electric ATV212HD45N4?

The ATV212HD45N4 is protected by an IP21 rating and has a continuous current rating of 65.9 A. This implies that it is safeguarded from solid objects that exceed 12 mm in diameter and water drops that descend vertically.

What are the input voltage range and the maximum short-term current for the ATV212HD45N4?

For the ATV212HD45N4, the maximal short-term current is 83.8 A, and the input voltage range is 380-480 V AC. These specifications guarantee consistent functionality in a variety of electrical environments.

What are the physical dimensions and weight of the Schneider Electric ATV212HD45N4?

The ATV212HD45N4 is approximately 21 kg in weight and measures 241 mm in width, 550 mm in height, and 245 mm in depth. It is effortless to install and transport due to its manageable weight and compact dimensions.
