Schneider Electric ATV630D30N4

Schneider Electric Atv630D30N4

Schneider Electric ATV630D30N4

Among the Altivar Process ATV600 family of high-performance VSDs, the ATV630D30N4 stands out. This VSD is perfect for optimizing energy usage and enhancing operating efficiency in diverse industrial situations. It has strong features, versatile connections, and superior motor control capabilities, making it ideal for demanding process and utility applications.

Technical Specifications:

The ATV630D30N4 can handle ordinary and heavy-duty motor applications with its 380–480V supply voltage range. It can meet many operating needs because it works with synchronous and asynchronous motors. An incorporated EN/IEC 61800-3 category C2 and C3 EMC filter ensures electromagnetic compatibility.

Forced convection cooling keeps the device running smoothly in tough situations. The nominal switching frequency is 4 kHz, but its derating factor permits adjustments from 2 to 12 kHz. The continuous output current is 61.5 A at 4 kHz for ordinary duty and 46.3 A for severe load.

The ATV630D30N4 supports Ethernet, Modbus TCP, and serial data transfer. Complete motor control and sixteen preset speeds are supported. Different operational needs are met by the motor's 30 kW normal duty and 22 kW heavy-load ratings.

The ATV630D30N4 is easy to install in industrial environments because of its small size (8.90 inches wide, 26.50 inches tall, 10.67 inches deep). The 61.73-lb device is easy to install. Easy wall mounting allows you to place it wherever for maximum efficiency and convenience.

IP21-rated VSD housing satisfies IEC 61800-5-1 improved operating safety and lifetime. The product allows for robust, lasting vertical mounting with a ±10 degree variation. The gadget regulates heat by dissipating 93 W by natural convection and 640 W by forced convection at 380 V and 4 kHz.

Connectivity and Communication:

Ethernet and Modbus TCP support the ATV630D30N4's multiple ports. These qualities improve control, data sharing, and industrial network integration. VSD control blocks are local control and diagnostic tools with removable screw connections for ease of installation and maintenance. RJ45 Ethernet with Modbus TCP allows reliable and efficient data delivery. Its data formats and transmission rates (4800 bps to 38.4 Kbps) make it suitable for many communication needs.

Environmental and Safety Features:

The ATV630D30N4 is built to endure many conditions. Its 63.5 dB low decibel level makes it appropriate for noisy environments. The device works without derating from 5 to 122 °F and with a derating factor up to 140 °F, ensuring constant performance in different conditions.

VSDs have a safe torque-off function, motor phase break protection, and drive and motor external heat protection. Safety is their top priority. These characteristics improve reliability and safety, lowering maintenance costs and downtime.

Frequently Asked Questions:

What is the IP rating and supply frequency for the ATV630D30N4?

The ATV630D30N4 from Schneider Electric can withstand a supply frequency range of 50 to 60 Hz with a margin of error of ±5% and has an IP21 rating. Because of this, it can be used in places where basic protection from dust and vertical water drops is necessary.

What is the analog input type and the noise level of the ATV630D30N4?

The VSD has three analog inputs that may be set to different voltages or currents (0...20 mA) and has a noise level of 63.5 dB. This setup keeps noise levels low and allows for versatile signal processing.

What are the mounting options and environmental certifications for the ATV630D30N4?

The ATV630D30N4 has several certifications, including UL, CSA, and TÜV, and it may be mounted on the wall. The installation is guaranteed to be secure and in accordance with international safety standards, thanks to these alternatives and certificates.

Product Specifications Table:

Attribute Specification
Product Series Altivar Process ATV600
Manufacturer Schneider Electric
Power (Normal Duty) 30 kW
Power (Heavy Duty) 22 kW
Continuous Output Current (Normal Duty) 61.5 A at 4 kHz
Continuous Output Current (Heavy Duty) 46.3 A at 4 kHz
IP Degree of Protection IP21 IEC 61800-5-1
Cooling Method Forced Convection
Switching Frequency 2 to 12 kHz adjustable
Communication Protocols Ethernet, Modbus TCP, Modbus serial
