The Schneider Electric XBTF034510 is a user-friendly Operator Interface Terminal with useful features. It belongs to the Magelis XBT F range, offering a vibrant color display. The VGA resolution ensures clear visuals and effortlessly handles complex HMI (Human-Machine Interface) applications.
As a renowned provider of industrial automation systems, Schneider Electric ensures that the XBTF034510 HMI fulfills the highest quality and reliability standards. The compact dimensions and lightweight design make installation easy.
Technical Specifications:
The Schneider Electric XBTF034510 is a reliable operator interface terminal that features a 10.4-inch (264 mm) touch screen. The screen is a color display with a VGA resolution of 640x480 pixels, ensuring clear and detailed visual output.
The voltage limit for this terminal is 18 to 30 V DC, with a power consumption of 35 watts, making it energy efficient. The dimensions of this operator interface terminal are 330 mm in length, 230 mm in width, and 80 mm in height. The weight of 2 kg ensures that it is manageable to install or relocate.
The Schneider Electric XBTF034510 has a Pentium processor and 96MB of memory, providing sufficient capacity for handling complex HMI applications. This operator interface terminal supports various communication protocols, including Modbus Master, Ethernet TCP/IP Modbus, and Jbus Master, enhancing the terminal's versatility for various industries.
Environmental Specifications:
The Schneider Electric XBTF034510 operates efficiently within a temperature range of +32 to +113 °F (0 to 45 °C), ensuring stable performance in cool and warm environments, making it versatile for different industrial settings. The terminal supports humidity levels from 0 to 85%, reducing the risk of malfunction due to humidity and ensuring consistent operation in diverse conditions.
The XBTF034510 terminal can withstand temperatures ranging from -4 to +140 °F for storage, ensuring the terminal remains functional and ready for use after storage. The terminal is designed with IP65 protection per IEC529, making it resistant to dust and water ingress and suitable for use in dusty or wet environments without compromising its functionality.
Modes of Operation:
The Schneider Electric XBTF034510 terminal operates in three primary modes: application transfer, operating mode, and confidential mode. Application Transfer Mode enables the transfer of applications and protocols between the XBT-L1000 software and the terminal.
Transfers can be done locally via a direct connection or remotely via a PLC network. In operating mode, the terminal is used for online system control. This includes PLC control, displaying information and variables, managing alarms, entering values, and executing discrete commands.
Confidential mode provides access to advanced functions that require higher security levels. Access is controlled via password protection to ensure that only authorized personnel can modify critical settings. This mode allows for modifying control system parameters, configuration of communication protocols, and other sensitive operations.
Frequently Asked Questions:
How to set up communication for Schneider Electric XBTF034510 Operator Interface Terminal?
Use Ethernet or Modbus protocols to connect the terminal to your network, ensuring proper configuration for seamless communication. Verify that all network settings such as IP addresses and subnet masks are correctly configured to avoid connectivity issues.
What precautions should be taken during the installation of Schneider Electric XBTF034510?
Ensure power is disconnected before installation. Follow the provided manual for proper wiring and secure mounting to prevent electrical hazards. Additionally, use appropriate personal protective equipment (PPE) to safeguard against accidental electrical shocks.
How to ensure optimal performance of the Schneider Electric XBTF034510?
Regularly update the firmware and software to the latest versions. Keep the terminal clean and free from dust to maintain its IP65 rating. Schedule periodic inspections to check for any signs of wear or damage that could affect performance.
Product Specifications Table
| Attribute | Specification |
|---|---|
| Screen Size | 10.4 inch (264 mm) |
| Resolution | 640x480 pixels |
| Color Screen | Yes |
| Supply Voltage | 24 V DC |
| Power Consumption | 35 W |
| Dimensions | Length 330 x Width 230 x Height 80 (mm) |
| Weight | 2 kg |
| Processor | Pentium |
| Memory | 96 MB |
| Degree of Protection | IP65 per IEC529 |
