TECHNICAL SPECIFICATIONS

FANUC A06B-6111-H015#H550

The FANUC A06B-6111-H015#H550 spindle amplifier module is a high-performance, energy-efficient solution for controlling spindle motors in milling machines, lathes, grinders, and grinders drilling machines, and other machining centers. It features advanced control algorithms and a compact, space-saving design, making it a suitable option for manufacturing companies.

Technical Specifications of FANUC A06B-6111-H015#H550:

This amplifier can be used for various industrial applications because of its maximum output of 55 kW and rated output of 15 kW.

It has a rated input current of 62A and runs on a power source that ranges from 200 to 240VAC. The amplifier's maximum output current and regenerative discharge power is 147A and 13 kW, respectively.

The integrated regenerative circuit of this servo amplifier is one of its essential characteristics. The amplifier can use the energy typically wasted for heating during operation with this circuit. This function can help the CNC system operate more effectively overall and use less energy.

The FANUC A06B-6111-H015#H550 servo amplifier's control circuit has a pulse coder interface that enables it to read position and speed data from the pulse coder of the CNC machine. This interface ensures precise and accurate control of the machine's servo motor.

This servo amplifier's frequency range depends on the input power supply frequency. When operated with a 50 Hz input, the frequency range is 0-600 Hz. When operated with a 60 Hz input, the frequency range is 0-720 Hz. Adjust the amplifier's output frequency range in increments of 0.01 Hz.

Regarding physical dimensions, it measures approximately 350 mm x 150 mm x 300 mm (13.78 in x 5.91 in x 11.81 in) and weighs about 6.3 kg.

Salient Features of the Module:

The FANUC A06B-6111-H015#H550 spindle amplifier module boasts an exceptional high-speed response, facilitated by its great 0.5 ms response time. It enables precise control of spindle motors, ensuring smooth and accurate operation. As such, this exceptional module is a perfect fit for high-speed machining requirements and other demanding applications.

Another impressive feature of this module is its flexibility to interface with many sensors and encoders, making it an ideal solution for use in diverse CNC systems.

Environmental Conditions:

The FANUC A06B-6111-H015#H550 servo amplifier module is built to withstand challenging conditions like high temperatures, dust, and vibration. The module has a maximum ambient operating temperature of 55°C (131°F), making it appropriate for use in environments with high heat output or elevated ambient temperature.

Regarding humidity, the module can operate in environments with up to 95% relative humidity without condensation. It qualifies it for usage in settings with high quantities of moisture, including processing facilities or manufacturing plants.

General Usage Guidelines:

Make sure to install and secure the module properly. Install the module in a location that meets its environmental and electrical requirements. Ensure that all connections are correct and that there are no missing or damaged parts..

Check the module's functionality after turning it on. Look for any error messages or warning lights on the front panel that can point to a problem with the module or the attached motor.

Adjust the operating parameters of the module to suit the specific application. It may include adjusting the motor's speed, torque, and other settings to achieve the desired performance.

Take the necessary steps to fix any concerns. It may need changing the module's settings, changing out damaged parts, or getting help from a trained expert.
