TECHNICAL SPECIFICATIONS

FANUC A06B-6117-H109

FANUC, a global leader in automation technology and robotics systems, has created the A06B-6117-H109 servo amplifier - an impressive member of their renowned A06B-6114 family. This product delivers dependable performance with its advanced features and seamless integration with other essential FANUC components.

Technical Specifications

The A06B-6117-H109 is a 2-axis servo amplifier that controls servo motors precisely and powerfully in various motion control applications. The I SV 360 is a high-performance servo amplifier for industrial automation.

This servo amplifier's power supply voltage is 200-240VAC, with a rated output current of 115A and a nominal maximum current of 360A. The A06B-6117-H109 has a Serial (RS-232C/422) communication interface for easy integration with other systems.

The A06B-6117-H109 operates in the 0°C to 55°C temperature range and can be stored in the -20°C to 60°C temperature range. The servo amplifier measures 150mm x 80mm x 230mm and weighs about 10.7kg. It dissipates 34W of total heat. You need to include a DBM (dynamic brake module) with a rating of 360 for this module to function properly.

Operating Conditions

The A06B-6117-H109 servo amplifier can function in various industrial automation applications if it meets specific operating conditions.

The non-condensing humidity level in the operating environment should be between 10 and 90 percent, and the vibration level should be less than 0.5G. Check that the voltage from the power supply falls within the range of 200-240 VAC specified, and make sure that it is stable and does not fluctuate.

The servo amplifier can operate at altitudes of up to 1000 meters (3281 feet) without performance degradation. Install the amplifier in a clean and dry environment to avoid accumulating dust and debris, which can affect the amplifier's performance.

Installation and Transportation

Ensure the installation area is free of dust, moisture, and other foreign matter that could harm the unit. The unit's installed surface should be vibration-free and stable to prevent vibration-induced damage to the internal components.

To ensure that the unit (A06B-6117-H109) is installed correctly and by the recommended guidelines, the installation should be performed by a trained and qualified technician. Before turning on the unit's power supply, ensure that all connections are secure and properly installed.

Handle the amplifier cautiously to avoid damaging its internal components. Ensure the temperature is between -20°C and 60°C during transportation. Securely fasten the unit in a sturdy and protective container to prevent movement during transportation.

To be safe, the company delivers this product (A06B-6117-H109) in safe and secure packaging via their trustworthy logistics partners.

Safety Precautions

Only personnel with proper training and qualifications should handle and operate the A06B-6117-H109 servo amplifier. Please follow the manual provided for the FANUC A06B-6117 and carry out all procedures. It will help ensure that you are completing each step accurately and efficiently.

Before you attempt to handle the device, double-check that the power supply for the servo amplifier is disconnected and turned off. It is important to remember not to touch any of the servo amplifier's internal components either while it is running or right after you have turned it off. Some of the components inside may be hot, which could cause injury.

When installing the servo amplifier, ensure it is properly grounded to avoid potential electrical hazards.

FANUC A06B-6117-H205 is a powerful servo amplifier that enables precise motor movements at adjustable speeds, positions, and torques. Compatible with the alpha i, beta I, and SVM series motors of the renowned FANUC product line, this advanced device allows for many automated possibilities.

Technical Specifications

The A06B-6117-H205 servo amplifier is a high-performance, dependable, and user-friendly device for precisely controlling servo motors. This servo amplifier is an essential part of a CNC machine tool system. Integrate it easily with FANUC CNC systems.

The servo amplifier has a small footprint, measuring 130mm x 300mm x 270mm and weighing about 4.6kg. It has a DC voltage range of 170V to 253V and is suitable for various industrial applications.

The servo amplifier (A06B-6117-H205) has a nominal current limit of 20A and a rated output current of 6.5A. The servo amplifier includes a power supply with a rated power output of 6.5W. The total heat dissipation of the amplifier is 17W.

Operating Conditions

The operating temperature range recommended for optimal performance is 0 degrees Celsius to 55 degrees Celsius, and the recommended humidity range is 10 percent to 95 percent non-condensing. Temperatures that fall outside of this range have the potential to adversely affect the A06B-6117-H205 amplifier's performance as well as its lifespan.

Vibration has the potential to cause damage to the amplifier's internal components, which in turn can harm the device's performance. We recommend limiting the vibration acceleration to 4.9 meters per second. This amplifier has an altitude range of up to a thousand meters. Above this elevation, the air density begins to drop, impacting the amplifier's ability to cool down and perform.

Installation and Transportation

Ensure you install the A06B-6117-H205 amplifier in an environment free from vibration, dust, and moisture. The mounting surface should be flat and level to ensure proper alignment and performance.

Mount the servo in a suitable location that provides adequate ventilation and protection from environmental factors such as moisture and dust to prevent overheating. Also, ensure the amplifier is securely mounted to avoid movement or vibration. Turn off the power and properly ground all electrical connections before connecting the servo motor and power supply to avoid electrical shock or damage.

When transporting the servo amplifier, it is critical to ensure it is properly packaged and secured to avoid damage. Transport the servo amplifier in its original packaging or a suitable protective container to avoid damage. During transportation, the ambient temperature should be between -20°C and +60°C.

Safety Precautions

The A06B-6117-H205 servo amplifier also includes several safeguards to ensure safe and dependable operation. Overcurrent protection, overvoltage protection, and Undervoltage protection are among the features. The amplifier also has a thermal protection function that monitors its temperature and shuts down the system if it exceeds safe levels.

When installing and operating the A06B-6117-H205, take the recommended precautions. These precautions include properly grounding the system, using appropriate protective equipment when working on it, and adhering to all safety instructions in the user manual.

Before handling the unit, make sure the servo amplifier's power supply is turned off and disconnected. Ensure the servo amplifier is appropriately grounded when installing it to avoid electrical hazards.
