AMK KE 20
SKU: KE 20
This product is not available for online purchase.
Use the Request a quote to get the pricing
Description
The KE 20 is engineered for servo applications requiring higher power. It operates with an input voltage of 3 x 400–480 V AC at 47–63 Hz and an input current of 30 A. The module provides an output power of 20 kW, peaking at 40 kW for up to 60 seconds. It achieves an efficiency of approximately 99% and incorporates an integrated braking transistor. An external brake resistor with a minimum resistance of 22 Ω can be connected. Protective features include line overcurrent (I²t), short circuit, and excess temperature monitoring. The KE 20 has a module width of 85 mm and weighs approximately 4.2 kg.
Request a Price Quote
-
Buying Options
-
Description
The KE 20 is engineered for servo applications requiring higher power. It operates with an input voltage of 3 x 400–480 V AC at 47–63 Hz and an input current of 30 A. The module provides an output power of 20 kW, peaking at 40 kW for up to 60 seconds. It achieves an efficiency of approximately 99% and incorporates an integrated braking transistor. An external brake resistor with a minimum resistance of 22 Ω can be connected. Protective features include line overcurrent (I²t), short circuit, and excess temperature monitoring. The KE 20 has a module width of 85 mm and weighs approximately 4.2 kg.
-
