FANUC A06B-6127-H209

An advanced servo amplifier unit from the 6117 series, the FANUC A06B-6127-H209, is made to make CNC machining more efficient and precise. This dual-axis servo drive amplifies power, provides high-performance control, and integrates smoothly with CNC systems for complicated industrial applications.

Technical Specifications:

The FANUC A06B-6127-H209 can handle a wide variety of industrial power circumstances since it operates within a rated input voltage range of 565-679 V. Its adaptability to different power inputs makes it useful in a wide range of contexts, and its reliability in the face of voltage fluctuations further adds to its versatility.

The linked motors receive strong power from this servo amplifier, which has a rated output current of 18.2 A for the L and M axes. The dual-axis arrangement facilitates complex machining jobs by enabling the synchronized and exact movements required for high-precision manufacturing processes.

The A06B-6127-H209 has a maximum output voltage of 480 V, proving its competence in driving motors. The motors' ability to reach the required torque and speed for demanding applications is enhanced by their high output voltage.

With its 11.6 kW power rating, the servo amplifier caters to the demands of robust industrial machinery. This power capacity allows for long periods of peak performance, making it perfect for demanding environments that require dependability and durability.

The A06B-6127-H209 is a two-axis model with SVAMP 30I, Ai SV2-80/80/HV) designation. This dual-axis capability is crucial for CNC systems that necessitate exact two-axis coordination. It greatly improves the adaptability and usefulness of CNC systems by guaranteeing the smooth and precise execution of complicated machining operations.

CNC Integration:

Regarding CNC systems, the FANUC A06B-6127-H209 is an integral component, not an afterthought. Because of its dual-axis capability, this servo drive is well-suited to the precise machining tasks required in the CNC environment, where accuracy is paramount.

Its job is to increase power with pinpoint accuracy so the CNC system can carry out directions precisely. Because of this integration, the CNC system runs smoothly, and the operator has more control over the motor operations, producing higher-quality products.

Safety Preventions:

Several safety elements are included in the FANUC A06B-6127-H209 to guarantee secure operation, which is of utmost importance in any industrial setup. The system is protected from possible harm caused by electrical fluctuations by the built-in overvoltage and undervoltage protection of the servo amplifier. In addition, it has built-in safeguards to avoid electrical problems that could cause equipment to malfunction or potentially cause harm, such as short-circuit prevention.

The A06B-6127-H209 has built-in thermal protection features to prevent overheating while in use. This protects the amplifier and any attached motors. Even after extended usage, the unit's optimal operating temperatures are maintained thanks to its design, which enables effective heat dissipation.

In addition, the servo amplifier features state-of-the-art fault detection systems that monitor for irregularities and notify operators immediately. These solutions improve CNC operations' overall reliability and safety by facilitating rapid remedial actions and reducing downtime.

Frequently Asked Questions:

What is the FANUC A06B-6127-H209's rated input voltage and power rating?

This FANUC A06B-6127-H209 is rated for input voltages between 565 and 679 V. A power rating of 11.6 kW means it can easily handle heavy-duty industrial tasks.

In what ways does the FANUC A06B-6127-H209's dual-axis configuration optimize CNC operations?

The dual-axis arrangement makes precise coordination between two axes possible, improving the CNC system's capacity to execute complicated and coordinated machining operations.

What safety features are included in the FANUC A06B-6127-H209?

It offers protection against overvoltage, undervoltage, and short circuits. It also includes thermal protection to avoid overheating and further guarantees safe and dependable operation.

Product Specifications Table:
