Mitsubishi FR-E520-3.7K-NA
Mitsubishi FR-E520-3.7K-NA
The Mitsubishi FR-E520-3.7K-NA is a high-performance variable frequency drive (VFD) specifically engineered to regulate the speed and torque of three-phase motors. This VFD, part of the FR-E520 series, is designed to optimize motor control in various industrial applications, thereby increasing productivity and operational efficiency.
Technical Specifications
Due to its numerous technical features, the Mitsubishi FR-E520-3.7K-NA is an optimal choice for industrial applications. It accommodates a rated capacity of 7 kVA and an applicable motor capacity of 3.7 kW.
The drive can withstand an excess capacity of 150% for a maximum of 60 seconds and has a rated current of 17.5A. This model is powered by a three-phase power supply that operates at 50Hz/60Hz and has a voltage range 200V to 240V.
The drive is engineered to accommodate AC (DC) voltage fluctuations from 170V to 264V. It guarantees robust start-ups by providing 150% or greater starting torque at 1Hz and 200% or greater at 3Hz. The output voltage is maintained at 230V, with a frequency accuracy within 0.01% of the set output frequency.
The drive's optimal operation necessitates a power supply system capacity of 9 kVA, and the permissible frequency fluctuation is ±5%. The FR-E520-3.7K-NA has a carrier frequency of up to 15 kHz, which minimizes noise during operation.
The drive also incorporates a variety of protective functions, including overcurrent, overvoltage, undervoltage, and overheating protection, to ensure the equipment's safety and reliable operation. The VFD also includes a built-in PID control function that assists in the optimal regulation of process variables. The Mitsubishi FR-E520-3.7K-NA has a forced air-cooling system and an enclosed type (IP00) protective structure to regulate heat effectively.
. The drive, which weighs 2.2 kg, can operate in an ambient temperature range of -10°C to +50°C and an ambient humidity of 90%RH or lower. The temperature range for storage is -20°C to +65°C. The drive's compact dimensions, which are 128mm (W) x 140mm (H) x 150mm (D), facilitate installation in environments with limited space.
Mounting Specifications
The Mitsubishi FR-E520-3.7K-NA offers a variety of mounting options to accommodate a wide range of installation needs. It is intended to be installed at a maximum altitude of 1000 meters above sea level.
The drive's ability to endure vibrations of up to 5.9 m/s² guarantees stability and dependability in various operational environments. It also includes easily accessible terminals, which simplifies wiring and reduces the time required for installation.
Display Specifications
The drive is equipped with an LED display that displays the operating status (L.RUN, SD, RD, L.ERR), alarm (ALARM), and power application (POWER). Additionally, it furnishes real-time information regarding the operating status, set frequency, output current, and output voltage.
This enables effortless monitoring and troubleshooting, guaranteeing the system's efficient and uninterrupted operation. A keypad is also incorporated into the display to set and adjust parameters.
Frequently Asked Questions
What is the Mitsubishi FR-E520-3.7K-NA's overload capacity?
The Mitsubishi FR-E520-3.7K-NA can withstand an excess of 150% for 60 seconds. This enables the drive to withstand temporary increases in capacity without damage.
What is the initial torque of the Mitsubishi FR-E520-3.7K-NA?
The Mitsubishi FR-E520-3.7K-NA generates a starting torque of 150% or greater at 1Hz and 200% or greater at 3Hz. This guarantees a strong start-up performance for large loads.
What is the cooling technique employed in the Mitsubishi FR-E520-3.7K-NA?
The FR-E520-3.7K-NA employs a forced air cooling system. This approach effectively regulates heat dissipation to preserve optimal operating temperatures.
Product Specifications Table:
| Attribute | Specification |
|---|---|
| Applicable Motor Capacity | 3.7 kW |
| Rated Capacity | 7 kVA |
| Rated Current | 17.5A |
| Overload Capacity | 150% for 60 seconds |
| Input Voltage Range | 200V to 240V, 50Hz/60Hz |
| Permissible AC (DC) Voltage Fluctuation | 170V to 264V |
| Starting Torque | 150% or more at 1Hz, 200% or more at 3Hz |
| Output Voltage | 230V |
| Frequency Accuracy | Within 0.01% of set output frequency |
| Cooling System | Forced air cooling |
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
Description
Mitsubishi FR-E520-3.7K-NA
The Mitsubishi FR-E520-3.7K-NA is a high-performance variable frequency drive (VFD) specifically engineered to regulate the speed and torque of three-phase motors. This VFD, part of the FR-E520 series, is designed to optimize motor control in various industrial applications, thereby increasing productivity and operational efficiency.
Technical Specifications
Due to its numerous technical features, the Mitsubishi FR-E520-3.7K-NA is an optimal choice for industrial applications. It accommodates a rated capacity of 7 kVA and an applicable motor capacity of 3.7 kW.
The drive can withstand an excess capacity of 150% for a maximum of 60 seconds and has a rated current of 17.5A. This model is powered by a three-phase power supply that operates at 50Hz/60Hz and has a voltage range 200V to 240V.
The drive is engineered to accommodate AC (DC) voltage fluctuations from 170V to 264V. It guarantees robust start-ups by providing 150% or greater starting torque at 1Hz and 200% or greater at 3Hz. The output voltage is maintained at 230V, with a frequency accuracy within 0.01% of the set output frequency.
The drive's optimal operation necessitates a power supply system capacity of 9 kVA, and the permissible frequency fluctuation is ±5%. The FR-E520-3.7K-NA has a carrier frequency of up to 15 kHz, which minimizes noise during operation.
The drive also incorporates a variety of protective functions, including overcurrent, overvoltage, undervoltage, and overheating protection, to ensure the equipment's safety and reliable operation. The VFD also includes a built-in PID control function that assists in the optimal regulation of process variables. The Mitsubishi FR-E520-3.7K-NA has a forced air-cooling system and an enclosed type (IP00) protective structure to regulate heat effectively.
. The drive, which weighs 2.2 kg, can operate in an ambient temperature range of -10°C to +50°C and an ambient humidity of 90%RH or lower. The temperature range for storage is -20°C to +65°C. The drive's compact dimensions, which are 128mm (W) x 140mm (H) x 150mm (D), facilitate installation in environments with limited space.
Mounting Specifications
The Mitsubishi FR-E520-3.7K-NA offers a variety of mounting options to accommodate a wide range of installation needs. It is intended to be installed at a maximum altitude of 1000 meters above sea level.
The drive's ability to endure vibrations of up to 5.9 m/s² guarantees stability and dependability in various operational environments. It also includes easily accessible terminals, which simplifies wiring and reduces the time required for installation.
Display Specifications
The drive is equipped with an LED display that displays the operating status (L.RUN, SD, RD, L.ERR), alarm (ALARM), and power application (POWER). Additionally, it furnishes real-time information regarding the operating status, set frequency, output current, and output voltage.
This enables effortless monitoring and troubleshooting, guaranteeing the system's efficient and uninterrupted operation. A keypad is also incorporated into the display to set and adjust parameters.
Frequently Asked Questions
What is the Mitsubishi FR-E520-3.7K-NA's overload capacity?
The Mitsubishi FR-E520-3.7K-NA can withstand an excess of 150% for 60 seconds. This enables the drive to withstand temporary increases in capacity without damage.
What is the initial torque of the Mitsubishi FR-E520-3.7K-NA?
The Mitsubishi FR-E520-3.7K-NA generates a starting torque of 150% or greater at 1Hz and 200% or greater at 3Hz. This guarantees a strong start-up performance for large loads.
What is the cooling technique employed in the Mitsubishi FR-E520-3.7K-NA?
The FR-E520-3.7K-NA employs a forced air cooling system. This approach effectively regulates heat dissipation to preserve optimal operating temperatures.
Product Specifications Table:
| Attribute | Specification |
|---|---|
| Applicable Motor Capacity | 3.7 kW |
| Rated Capacity | 7 kVA |
| Rated Current | 17.5A |
| Overload Capacity | 150% for 60 seconds |
| Input Voltage Range | 200V to 240V, 50Hz/60Hz |
| Permissible AC (DC) Voltage Fluctuation | 170V to 264V |
| Starting Torque | 150% or more at 1Hz, 200% or more at 3Hz |
| Output Voltage | 230V |
| Frequency Accuracy | Within 0.01% of set output frequency |
| Cooling System | Forced air cooling |
All products (new, refurbished, and repairs) are covered by the Industrial Automation Company's 2 Year Warranty. Manufacturer's Warranty does not apply.
