TECHNICAL SPECIFICATIONS

FX1N-60MT-ES/UL

The FX1N-60MT-ES/UL model is a highly developed and dependable programmable controller member of the renowned FX family. It continuously cycles through an internal programming logic that is user-determined, which enables it to instantly detect changes in input data while simultaneously producing output signals at set intervals. This enables it to perform multiple tasks simultaneously. Engineers working in a wide variety of sectors benefit from the dependable control algorithms made available by this adaptable system, which is more commonly known as PLC or programmable controllers.

Specifications (FX1N-60MT-ES/UL):

The FX1N-60MT-ES/UL model offers robust programming and control support with 16-bit counters providing up to 184 latched points and 32-bit counters, which provide 20 general points and 16 latched points. This versatile programmable controller also supports symbolic relay language and step ladder-style programming allowing for the creation of SFC programs. The 384 available M coils (general), 1152 latching points, and 256 special Auxiliary Relay M Coils offer enhanced flexibility in system design.

The FX1N-60MT-ES/UL is an advanced programmable controller with a substrate coating that can outperform accuracy and speed. With the most modern high-speed CPU incorporated, this model can precisely execute specified instructions within 0.55 to 100 microseconds - greatly improving control performance for multiple applications.

This highly advanced programmable controller model, the FX1N-60MT-ES/UL, has powerful adaptive capabilities that allow it to adjust the speed of production lines quickly. These capabilities enable it to adjust the speed of production lines quickly. This guarantees a consistent output of products of the highest possible quality and comes equipped with an 8000-step built-in programming capacity made possible by EEPROM memory.

Data registers have 7128 general points, 872 latched, and 16 index points, while the state relay (S Coil) also contains 1K Latches and 10 initial points from 0 - 9, respectively. The 100ms timer spans 0 to 3276 secs while the shorter 10msec version goes up to 327 seconds. The pointers in the model have 128 points for CALL & 8 points for interrupt, making this highly responsive model ideal for industrial automation.

Software Version for FX1N-60MT-ES/UL:

The FX1N-60MT-ES/UL CPU offers tremendous potential thanks to the additional peripherals and programming features it incorporates. Users must upgrade their currently installed software and hardware tools to use this model to its full potential. On the other hand, those who want to obtain performance comparable to that of a version 3.30 running unit can continue to use their existing setup without making any necessary adjustments.

General Safety Instructions for FX1N-60MT-ES/UL:

Engineers must be knowledgeable when handling the PLC model FX1N-60MT-ES/UL in automated equipment building. It is critical to confirm whether there has been any dual coiling, as incompatibility between two coils can thwart program operation while causing severe damage risks. Considering this potential risk, engineers should be sure their work follows all applicable local, state, and federal standards for qualification, education requirements, and licensing practices.

The PLC model FX1N-60MT-ES/UL is a powerful device accommodating multiple serial and parallel connections. Still, to ensure an optimal system operation, it should include no more than ten contacts per line of the ladder program resulting in a total limit of 24 connected outputs. Ensure each connection follows best practices for efficient performance.
