The efficient and reliable Siemens 6SL3130-7TE23-6AA3 is part of the SINAMICS S120 drive system. Book size Active Line Modules adjust DC link voltage for steady operation under variable line voltage settings. Its smooth integration and high performance make it ideal for industrial applications.

Technical Specifications:

Under typical industrial conditions, the Siemens 6SL3130-7TE23-6AA3 runs with a stable line connection voltage of 380 to 480 V 3 AC ± 10%. It supports 47–63 Hz line frequencies, making it compatible with many power systems. Active mode has a power factor of 1.0, but a reactive current setpoint can change it, while smart mode has a fundamental power factor greater than 0.96.

The DC link voltage is regulated and changeable in active mode, independent of the line voltage. Manufacturer values are 600 V for 380...400 V 3 AC and 625 V for 400...415 V 3 AC. The electronics power supply operates at 24 V DC with -15% to +20% tolerance. For 16 kW and 36 kW modules, a line filter package meets EN 55011 Class A1 and EN 61800-3 Category C2 radio interference suppression standards.

The 6SL3130-7TE23-6AA3 has 36 kW (40 HP) at 380 V and 460 V 3 AC and 0.98 efficiency. In S6 duty (40%), it produces 47 kW and 60 kW max. The DC link current is 79 A, with the input current specified at 58 A for 380 V 3 AC and 117 A for the maximum capacity. The electronics power supply needs 1.5 A at 24 V DC for stability.

The 6SL3130-7TE23-6AA3 communicates with the CU320 Control Unit and SINUMERIK 840D sl via DRIVE-CLiQ in the SINAMICS S120 drive system. It is CE low-voltage, EMC, and cULus-approved. IP20 protection makes it ideal for many industrial settings.

Durability and functionality are the goals of this Active Line Module. Its tiny form measures 150 mm wide, 380 mm high (629 mm with fan), and 270 mm deep. Internal air cooling weighs 10.3 kg, and exterior air cooling weighs 13.8 kilograms. The module's sound pressure is below 65 dB(A), ensuring industrial quietness.

Design and Cooling:

Internal air cooling with fans improves cooling efficiency in the Siemens 6SL3130-7TE23-6AA3. The ambient temperature can be 0 to 40 °C without derating and 55 °C with derating. It works up to 1000 m above sea level. However, performance must be adjusted to 4000 m.

Electrical and Power Loss:

The 6SL3130-7TE23-6AA3 requires 0.031 m³/s of cooling air for effective heat dissipation. Internal air cooling is 0.63 kW, and external air cooling is 0.135 kW and 0.495 kW, minimizing power loss. This design optimizes energy use, lowering operational expenses.

Frequently Asked Questions:

What is the power factor and rated voltage of the Siemens 6SL3130-7TE23-6AA3?

At both 380 V and 460 V 3 AC, the rated capacity is 36 kW (40 HP). The power factor in active mode is fixed at 1.0 and can be adjusted by inputting a reactive current setpoint.

What are the ambient temperature and installation altitude restrictions for the Siemens 6SL3130-7TE23-6AA3?

The permissible ambient temperature ranges from 0 to 40 °C without derating. The module functions efficiently up to an altitude of 1000 m, after which adjustments are necessary until it reaches 4000 m.

What are the cooling air requirements and power loss for the Siemens 6SL3130-7TE23-6AA3?

The internal air conditioning system's power loss is 0.63 kW. To facilitate effective heat dissipation, the cooling air requirement is 0.031 m³/s.

Product Specifications Table:

Attribute Specification
Line Connection Voltage 380 ... 480 V 3 AC ± 10%
Line Frequency 47 ... 63 Hz
Power Factor (Active Mode) 1.0 (adjustable by reactive current setpoint)
DC Link Voltage (Factory) 600 V (380 ... 400 V 3 AC), 625 V (400 ... 415 V 3 AC)
Rated Power 36 kW (40 HP)
Efficiency 0.98
Ambient Temperature Range 0 ... 40 °C without derating
Installation Altitude Up to 1000 m, adjustments up to 4000 m
Power Loss (Internal Cooling) 0.63 kW
Cooling Air Requirement 0.031 m³/s
